X18D206VM0BAA 7.0" 800×480 800cd/m2 Industrial Lcd Panel 133PPI

Large Image : X18D206VM0BAA 7.0" 800×480 800cd/m2 Industrial Lcd Panel 133PPI

Product Details:

Place of Origin:	JAPAN
Brand Name:	KOE
Certification:	ISO9001
Model Number:	TX18D206VM0BAA

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	1000PCS

Contact Now

X18D206VM0BAA 7.0" 800×480 800cd/m2 Industrial Lcd Panel 133PPI

Description

MODEL NUMBER:	TX18D206VM0BAA	BRAND:	KOE
SIZE:	7.0 Inch	RESOLUTION:	800(RGB)×480 [WVGA] 133PPI
BRIGHTNESS:	800 Cd/m² (Typ.)	TEMPERATURE RANGE:	Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 M/s²)
High Light:	7.0" 800×480 Industrial Lcd Panel , 800cd/m2 Industrial Lcd Panel , 133PPI TFT LCD Module

KOE TX18D206VM0BAA Application Features

Basic Information :	Manufacturer	Panel Model	Panel Type	Alias
Basic Information :		TX18D206VM0BAA	a-Si TFT-LCD , LCM	-
Environment :	RoHS State	Operating Temp.	Storage Temp.	Vibration Level
Environment :		-40 ~ 85 °C	-40 ~ 90 °C	5.0G (49.0 m/s²)
Used For :
Specific Features :

KOE TX18D206VM0BAA Optical Features

Basic Information :	Luminance (cd/m²)	Viewing Angle (L/R/U/D)	Response Time (ms)
	800 (Typ.)	85/85/85/85 (Typ.)(CR≥10)	30 (Typ.)(Tr+Td)
	Best View on	Display Mode	Contrast Ratio
	Symmetry	IPS, Normally Black, Transmissive	1000 : 1 (Typ.) (Transmissive)
Dispaly Color :	Color Temperature	Display Colors	White Coordinate
Dispaly Color :	6638K	262K (6-bit)	X:0.310; Y:0.330
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	73%	96%	74%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	76%	55%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation :	1.43 (Max.)(9 points)
Performance :	3D Tech	Sunlight Visibility	Reflectance
Performance :	-	Sunlight Readable

KOE TX18D206VM0BAA Mechanical Features

Panel Size :	7.0"
Pixel Features :	Pixel Format	Pixel Configuration	Pixel Pitch (mm)	Dot Pitch (mm)
Pixel Features :	800(RGB)×480 [WVGA]	RGB Vertical Stripe	0.1905×0.1905 [133PPI]	0.0635×0.1905
Mechanical Size :	Active Area (mm)	Bezel Area (mm)	Outline Dimension (mm)	Outline Depth (mm)
Mechanical Size :	152.4(H) × 91.44(V)	156.2(H) × 94.5(V)	167.7(H) × 109.45(V)	9.0/20.4 (Typ./Max.) mm
Outline Features :	Form Factor	Orientation	Aspect Ratio	Shape Style
Outline Features :	Flat Rectangle	Landscape type	15:9 (H:V)
Mounting :	Rear mounting Pole (4-M3)
Other Detail :	Weight	Panel Cover	Treatment
Other Detail :	231g (Typ.)

KOE TX18D206VM0BAA Electronics Features

Reverse Scan :	Yes (U/D, L/R)
Vertical Frequency :	60Hz Power Consumption :	4.59W (Typ.)

KOE TX18D206VM0BAA Backlight Features

Lamp Features:	Type	Position	Quantity	Shape	Life(Hours)	Lamp Exchange
Lamp Features:	WLED	Edge light type	-	-	70K(Typ.)	-
Interface Features :	Position	Backlight Driver				Type
Interface Features :	-	With LED Driver				Connector
Interface Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Interface Detail :	JST	SM02(8.0)B-BHS-1-TB	8.0 mm	2 pins	1 pcs	BLE-2PINS-VG
Driver Electrical :	Voltage Supply		Current Supply			Power Consumption
Driver Electrical :	12.0V (Typ.)		330/360mA (Typ./Max.)			3.96W (Typ.)

Overview Specs Stocks Suppliers Touch Panels OEM/ODM RFQs Driver Kits

KOE TX18D206VM0BAA Application Features

Basic Information :	Manufacturer	Panel Model	Panel Type	Alias
Basic Information :		TX18D206VM0BAA	a-Si TFT-LCD , LCM	-
Environment :	RoHS State	Operating Temp.	Storage Temp.	Vibration Level
Environment :		-40 ~ 85 °C	-40 ~ 90 °C	5.0G (49.0 m/s²)
Used For :
Specific Features :

Add to Favorites
Book Stock Alert
Book RFQ Alert
Add to Compare
North American Sales
日本販売

KOE TX18D206VM0BAA Optical Features

Basic Information :	Luminance (cd/m²)	Viewing Angle (L/R/U/D)	Response Time (ms)
	800 (Typ.)	85/85/85/85 (Typ.)(CR≥10)	30 (Typ.)(Tr+Td)
	Best View on	Display Mode	Contrast Ratio
	Symmetry	IPS, Normally Black, Transmissive	1000 : 1 (Typ.) (Transmissive)
Dispaly Color :	Color Temperature	Display Colors	White Coordinate
Dispaly Color :	6638K	262K (6-bit)	X:0.310; Y:0.330
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	73%	96%	74%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	76%	55%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation :	1.43 (Max.)(9 points)
Performance :	3D Tech	Sunlight Visibility	Reflectance
Performance :	-	Sunlight Readable	-

Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
Back to Top

KOE TX18D206VM0BAA Mechanical Features

Panel Size :	7.0"
Pixel Features :	Pixel Format	Pixel Configuration	Pixel Pitch (mm)	Dot Pitch (mm)
Pixel Features :	800(RGB)×480 [WVGA]	RGB Vertical Stripe	0.1905×0.1905 [133PPI]	0.0635×0.1905
Mechanical Size :	Active Area (mm)	Bezel Area (mm)	Outline Dimension (mm)	Outline Depth (mm)
Mechanical Size :	152.4(H) × 91.44(V)	156.2(H) × 94.5(V)	167.7(H) × 109.45(V)	9.0/20.4 (Typ./Max.) mm
Outline Features :	Form Factor	Orientation	Aspect Ratio	Shape Style
Outline Features :	Flat Rectangle	Landscape type	15:9 (H:V)
Mounting :	Rear mounting Pole (4-M3)
Other Detail :	Weight	Panel Cover	Treatment
Other Detail :	231g (Typ.)	-	-

Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
Back to Top

Add to Favorites
Book Stock Alert
Book RFQ Alert
Add to Compare
North American Sales
日本販売

KOE TX18D206VM0BAA Electronics Features

Reverse Scan :	Yes (U/D, L/R)
Vertical Frequency :	60Hz Power Consumption :	4.59W (Typ.)

KOE TX18D206VM0BAA Backlight Features

Lamp Features:	Type	Position	Quantity	Shape	Life(Hours)	Lamp Exchange
Lamp Features:	WLED	Edge light type	-	-	70K(Typ.)	-
Interface Features :	Position	Backlight Driver				Type
Interface Features :	-	With LED Driver				Connector
Interface Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Interface Detail :	JST	SM02(8.0)B-BHS-1-TB	8.0 mm	2 pins	1 pcs	BLE-2PINS-VG
Driver Electrical :	Voltage Supply		Current Supply			Power Consumption
Driver Electrical :	12.0V (Typ.)		330/360mA (Typ./Max.)			3.96W (Typ.)

Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
Back to Top

KOE TX18D206VM0BAA Interface Features

Panel Driving Electrical :	Voltage Supply		Current Supply			Power
Panel Driving Electrical :	3.3V (Typ.)		136/170mA (Typ./Max.)			0.627W (Typ.)
Interface Features :	Position	Signal				Type
Interface Features :	-	LVDS (1 ch, 6-bit)				Connector
Connector Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Connector Detail :	JAE	FI-SEB20P-HF13E-E1500	1.25 mm	20 pins	1 pcs	LVDS-20P1C6B-005C
