Product Details:
|
| MODEL NUMBER: | TX14D22VM1BPA | BRAND: | HITIACH |
|---|---|---|---|
| SIZE: | 5.7INCH | RESOLUTION: | 320(RGB)×240 (QVGA) 70PPI |
| BRIGHTNESS: | 320 Cd/m² (Typ.) | TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Highlight: | LVDS TFT LCD Panel,High Brightness TFT LCD 149PPI,SVGA 82PPI TFT LCD Panel |
||
| Basic Info : | Panel Brand |  |
Panel Model | TX14D22VM1BPA |
|---|---|---|---|---|
| Diagonal Size | 5.7" | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 80 °C |
| RoHS State | |
Vibration Rating | 3.0G (29.4 m/s²) | |
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 320(RGB)×240 [QVGA] | Dot Pitch | 0.120×0.360 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.360×0.360 mm (H×V) [70PPI] | |
| Mechanical Size : | Display Area | 115.2×86.4 mm (H×V) | Bezel Area | - |
| Outline Dim. | 131×102.2 mm (H×V) | Outline Depth | 8.6 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Touch Screen : | Touch Points | - | TP Signal | - |
| TP Controller | - | Touchscreen | 4-wire Resistive Touch, F/G | |
| Holes & Brackets : | Rear mounting holes (4-M2) | |||
| Other Features : | Weight | 150g (Typ.) | Surface | Antiglare |
| Basic Information : | Brightness | 320 cd/m² (Typ.) | Contrast Ratio | 350:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥5) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 12 o'clock | Response Time | 30 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.330; Wy:0.340 | Color Numbers | 262K (6-bit) |
| Color Temperature | 5614K | White Uniformity | 1.43 (Max.)(9 points)  |
|
| 1931 Color Gamlt : | NTSC Ratio | 56% | sRGB | 73% coverage |
| Adobe RGB | 57% coverage | DCI-P3 | 58% coverage | |
| Rec.2020 | 42% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Frequency : | 60Hz Reverse Scan :
| Yes (U/D, L/R) |
|---|---|---|
| Power Consumption : | 0.97W (Typ.) |
| Back-light Features: | Lamp Shape | Array | Lamp Type | WLED | Life Time | 40K(Typ.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 3S5P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 12.0±0.5V | Current Input | 60±10mA | ||
| Consumption | 0.72W (Typ.) |
|||||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JST | BHR-03VS-1 | 4.0 mm | 3 pins | 1 pcs | BLE-3PINS-ANC | |
| Signal Systerm : | CMOS (1 ch, 6-bit) | Logic Voltage | VSS≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3V (Typ.)(VDD) | Current Input | 57/75mA (Typ./Max.) | ||
| Consumption | 0.25W (Typ.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FA5B040HP1 | 0.5 mm | 40 pins | 1 pcs | DRGB-40P1C6B-350A | |
