Product Details:
|
| MODEL NUMBER: | DX09D10VM0AAA | BRAND: | HITACHI |
|---|---|---|---|
| SIZE: | 3.5 Inch | RESOLUTION: | 480(RGB)×800 (WVGA) 268PPI |
| BRIGHTNESS: | 280 (Typ.)(cd/m²) | TEMPERATURE RANG: | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 70 °C |
| Lamp Type: | WLED | SIGNAL LNTERFACE: | LVDS |
| Highlight: | VGA 76PPI TFT LCD Panel,45% NTSC TFT LCD Panel |
||
| Basic Info : | Panel Brand | Panel Model | DX09D10VM0AAA | |
|---|---|---|---|---|
| Diagonal Size | 3.5" | Application | ||
| Panel Type | LTPS TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -30 ~ 70 °C | Storage Temp. | -30 ~ 85 °C |
| RoHS State | Vibration Rating | - | ||
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 480(RGB)×800 [WVGA] | Dot Pitch | 0.0315×0.0945 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.0945×0.0945 mm (H×V) [268PPI] | |
| Mechanical Size : | Display Area | 45.36×75.6 mm (H×V) | Bezel Area | - |
| Outline Dim. | 49.71×84.7 mm (H×V) | Outline Depth | 1.356 mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio | 3:5 (H:V) | Shape Style | ||
| Other Features : | Weight | 9.20g | Surface | Antiglare |
| Basic Information : | Brightness | 280 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥2) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 35 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.300; Wy:0.330 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 7203K | White Uniformity | - | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 89% coverage |
| Adobe RGB | 70% coverage | DCI-P3 | 72% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Frequency : | 60Hz |
|---|---|
| Reverse Scan : | No |
| D-IC Detail : | Built-in R63302 |
| Back-light Features: | Lamp Shape | Parallel | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 1S6P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 3.2/3.5V (Typ./Max.) | Current Input | 15mA (Typ.) | ||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | Parallel RGB (1 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 1.8/2.8V (Typ.)(IOVCC/VCI) | Current Input | 30.0/50.0mA (Typ./Max.) | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| Kyocera Elco | 14-5804-050-000-829+ | 0.4 mm | 50 pins | 1 pcs | ||
