Product Details:
|
| MODEL NUMBER: | LMG6401PLGE | BRAND: | HITACHI |
|---|---|---|---|
| SIZE: | 5.1 Inch | RESOLUTION: | 240×128 50PPI |
| BRIGHTNESS: | 10cd/m² (Typ.) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Lamp Type: | WLED | SIGNAL LNTERFACE: | LVDS |
| Highlight: | TFT LCD Display SVGA 119PPI,LVDS TFT LCD Module |
||
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| LMG6401PLGE | STN-LCD , LCM | - | ||
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
| 0 ~ 50 °C | -20 ~ 60 °C | - | ||
| Application : |
|
|||
| Screen Size : | 5.1" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 240×128 | Rectangle | 0.50×0.50 mm | 0.50×0.50 mm [50PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 119.97×63.97 mm | 126.0×71.0 mm | 159.4×101 mm | 9.5 (Max.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 17:9 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 10 cd/m² (Typ.) | STN, Blue/Grey (Positive), Transflective | 3:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| 6 o'clock | 40 (Typ.)(CR≥1.4, Φ2-Φ1) | 250/300 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| - | Monochrome | - | |
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - |
| Refresh Rate : | 75Hz |
|---|---|
| Reverse Scan : | No |
| Driver IC List: | Built-in HD61830B |
| Driving Method : | Duty: 1/128 |
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| EL | Direct light type | - | 1 pcs | - | - | |
| EL Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 100V (Typ.) | 160mA (Max.) | |||||
| Operating Frequency | Startup Voltage | |||||
| 400Hz (Typ.) | ||||||
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 5.0V (Typ.) | 6.0mA (Typ.) | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| 1 pcs | 20 pins | |||||
whose pixels are arranged in Rectangle. As for mechanical detail, it features active area of 119.97(W)×63.97(H) mm, outline size of 159.4(W)×101(H)×9.5(D) mm, viewing area size of 126.0(W)×71.0(H) mm, net weight of 160g. As a STN, Blue/Grey (Positive), Transflective LCM product, LMG6401PLGE can provides 10 cd/m² display brightness 3:1 transimissive contrast ratio, 40 (Typ.)(CR≥1.4, Φ2-Φ1) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 250/300 (Typ.)(Tr/Td) ms., thus presenting a palette of Monochrome colors. This product adopted 1 pcs EL as it's backlight systerm which was placed as Direct light type. LMG6401PLGE utilizes 8-bit parallel as it's signal inputting systerm, which connected by 20 pins with power supply voltage of 5.0V (Typ.).
