Product Details:
|
| MODEL NUMBER: | AA101TA12 | BRAND: | Mitsubishi |
|---|---|---|---|
| SIZE: | 10.1INCH | RESOLUTION: | 1280×800 RGB |
| BRIGHTNESS: | 800CD/M2 | TEMPERATURE RANGE: | Storage Temp.: -40 ~ 80 °C Operating Temp.: -40 ~ 80 °C |
| Highlight: | QVGA 106PPI Lcd Display Panels,TFT LCD Panel LVDS |
||
| Basic Detail : | Manufacturer |  |
Model Name | AA101TA12 |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 10.1 inch | Designed For |
|
|
| Maximum Ratings : | OP Temperature | -40 ~ 80 °C | ST Temperature | -40 ~ 80 °C |
| Vibration Level | 1.0G (9.8 m/s²) | RoHS | |
| Basic Information : | Luminance | 800 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 12/12 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
Operating Mode | SWV, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 262K/16.7M (6-bit / 8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.30 (Max.)(5 points)  |
|
| 1931 Color Gamlt : | NTSC Ratio | 50% | sRGB | 70% coverage |
| Adobe RGB | 53% coverage | DCI-P3 | 52% coverage | |
| Rec.2020 | 38% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Pixel Features : | Number of Pixel | 1280(RGB)×800 [WXGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.0565×0.1695 mm | Pixel Pitch(W×H) | 0.1695×0.1695 mm [149PPI] | |
| Physical Size : | Active Viewing | 216.96(W)×135.6(H) mm | Overall Dim. | 231(W)×153.5(H) mm |
| Bezel Opening | 220.96(W)×139.6(H) mm | Overall Depth | 8.5/9.0 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:10 | Shape Style | ||
| Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Detail : | Mass | 310g | Surface | Antiglare, Hard coating (3H) |
| Refresh Rate : | 60Hz Reverse Scan :
| Yes (180°) |
|---|---|---|
| Power Consumption : | 8.7W (Typ.) |
| Signal Electrical : | Input Current | 0.56/1.3A (Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS (1 ch, 6/8-bit) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| HRS | DF19L-30P-1H | 1 pcs | 1.0 mm | 30 pins | ||
| Lamp Features: | Lamp Shape | 2 strings | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 2 strings | Life | 100K(Typ.) (Hours) | |
| Lamp Electrical : | Input Current | 120/130mA (Typ./Max.) | Input Voltage | 27/32.8V (Typ./Max.) | ||
| Consumption | 6.48W (Typ.) |
|||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JST | SM06B-SHLS-TF | 1 pcs | 1.0 mm | 6 pins | BLE-6PINS-NNCAAC | |
| Backlight Driver : | No | |||||
