FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10)

Large Image : FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10)

Product Details:

Place of Origin:	JAPAN
Brand Name:	LG DISPLAY
Certification:	ISO9001
Model Number:	LD550DUN-THB8

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	300PCS

Contact Now

FHD 40PPI 55in TFT LCD Panel 500cd/M2 LD550DUN-THB8 89/89/89/89 (Typ.)(CR≥10)

Description

MODEL NUMBER:	LD550DUN-THB8	BRAND:	LG DISPLAY
SIZE:	55 Inch	BRIGHTNESS:	500CD/M2
Lamp Type:	WLED	RESOLUTION:	1920(RGB)×1080, FHD, 40PPI
VIEWING ANGLEG:	89/89/89/89 (Typ.)(CR≥10)	TEMPERATURE RANGE:	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Highlight:	55in TFT LCD Panel , TFT LCD Panel 500cd/m2 , 40PPI Lcd Display Panels

LG Display LD550DUN-THB8 Application Details

Basic Detail :	Manufacturer LD550DUN-THB8Model Name Panel Type a-Si TFT-LCD , LCM Another Name LD550DUN (TH)(B8) Panel Size 55 inch Designed For
Maximum Ratings :	OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C

LG Display LD550DUN-THB8 Optical Details

Basic Detail :	Luminance 500 cd/m² (Typ.) Contrast Ratio 1400:1 (Typ.) (Transmissive) Good View at Symmetry Response Speed 8 (Typ.)(G to G) ms Viewing Angle 89/89/89/89 (Min.)(CR≥10) Operating Mode S-IPS, Normally Black, Transmissive
Color Performance :	Chromaticity Wx:0.279; Wy:0.292 Support Color 1.06B (8-bit + Dithering) Color Temperature 9972K White Variation 1.11/1.25 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 72% sRGB 99% coverage Adobe RGB 75% coverage DCI-P3 75% coverage Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LD550DUN-THB8 Interface Detail

Signal Electrical :	Input Current 0.83/1.08A (Typ./Max.) Input Voltage 12.0V (Typ.) Consumption 10.0/13.0W (Typ./Max.) Signal Interface LVDS (2 ch, 10-bit)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment JAE FI-RE51S-HF 0.5 mm 51 pins 1 pcs

LG Display LD550DUN-THB8 Lightting Details

Lamp Features :	Lamp Type WLED Amount - Position Direct light type Exchange - Lamp Shape - Lamp Life 60K(Typ.) (Hours)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment YEONHO 20022WR-14B2 2.0 mm 14 pins 1 pcs YEONHO 20022WR-12B2 2.0 mm 12 pins 1 pcs
Backlight Driver :	With LED Driver
Driver Electrical :	Input Voltage 24.0±2.4V Input Current 6.1/6.9A (Typ./Max.) Consumption 146.4/165.6W (Typ./Max.)

LG Display LD550DUN-THB8 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	10 pcs / box	-	1440×1140×950 mm

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
