TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY

TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY
TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY

Large Image :  TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: KOE
Certification: ISO9001
Model Number: TX20D203VM0BAA
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 50PCS
Contact Now

TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: TX20D203VM0BAA BRAND: KOE
SIZE: 8.0INCH RESOLUTION: 800(RGB)×480 [WVGA] 133PPI
BRIGHTNESS: 550CD/M2 TEMPERATURE RANGE: Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 M/s²)
High Light:

TFT LCD Panel LVDS

,

LVDS TFT LCD Module

,

VGA Touch Lcd Video Display

KOE TX20D203VM0BAA Application Details

Basic Info :
Panel Brand
TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 0
Panel Model
TX20D203VM0BAA
Diagonal Size
8.0"
Application
  • TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 1
Panel Type
a-Si TFT-LCD , LCM
Model Alias
-
Reliability :
Operating Temp.
-30 ~ 85 °C
Storage Temp.
-40 ~ 90 °C
RoHS State
TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 2
Vibration Rating
5.0G (49.0 m/s²)
Specific Features :
  • Wide Temperature
  • 5G Vibration
  • Hight Brightness
  • WLED Backlight
  • Life ≥ 70K hours
  • With LED Driver











































KOE TX20D203VM0BAA Mechanical Details

Pixel Features :
Pixel Format
800(RGB)×480, WVGA
Dot Pitch
0.0725×0.2175 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.2175×0.2175 mm (H×V) [116PPI]
Mechanical Size :
Display Area
174×104.4 mm (H×V)
Outline Dim.
175.5×106.2 mm (H×V)
Outline Dim.
189.5×119.4 mm (H×V)
Outline Depth
11.6 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
15:9 (H:V)
Shape Style

Other Features :
Weight
270g (Typ.)
Surface



















































KOE TX20D203VM0BAA Optical Details

Basic Information :
Brightness
550 cd/m² (Typ.)
Contrast Ratio
700:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
42 (Typ.)(Tr+Tf) ms
Color Performance :
Chromaticity
Wx:0.320; Wy:0.340
Color Numbers
16.7M (8-bit)
Color Temperature
6066K
Uniformity
1.43 (Max.)(9 points) TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 9
1931 Color Gamlt :
NTSC Ratio
55%
sRGB
74% coverage
Adobe RGB
58% coverage
DCI-P3
57% coverage
Rec.2020
41% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

























































KOE TX20D203VM0BAA Electronics Details

Frame Frequency :
60Hz
Reverse Scan :
No
Power Consumption :
3.46W (Typ.)























KOE TX20D203VM0BAA Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
70K(Typ.) Hours
Replacement
-
Lamp Shape
-
Position
Edge light type
Interface Features :
Type
Connector
Position
-
Lamp Driver
With LED Driver
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 11
JST
SM02(8.0)B-BHS-1-TB(LF)(SN)
8.0 mm
2 pins
1 pcs

Driver Electrical :
Voltage Input
12.0V (Typ.)
Current Input
150/200/260mA (Min./Typ./Max.)
Consumption
2.4W (Typ.)



















































KOE TX20D203VM0BAA Interface Details

Signal Systerm :
LVDS (1 ch, 8-bit)
Logic Voltage
-
Signal Electrical :
Voltage Input
3.3V (Typ.)
Current Input
320/370mA (Typ./Max.)
Consumption
1.06W (Typ.)
Interface Features :
Type
Connector
Position
-
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration TX20D203VM0BAA KOE 8.0" 800(RGB)×480 550 cd/m² Storage Temp.: -40 ~ 90 °C INDUSTRIAL LCD DISPLAY 12
JAE
FI-SEB20P-HF13E
1.25 mm
20 pins
1 pcs
