Product Details:
|
| MODEL NUMBER: | TX13D202VM5BAA | BRAND: | KOE |
|---|---|---|---|
| SIZE: | 5.0 Inch | RESOLUTION: | 640(RGB)×480, VGA, 159PPI |
| BRIGHTNESS: | 600 Cd/m² (Typ.) | TEMPERATURE RANGE: | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| High Light: | LVDS TFT LCD Panel,High Brightness TFT LCD 149PPI,SVGA 82PPI TFT LCD Panel |
||
| Basic Detail : | Manufacturer |  |
Model Name | TX13D202VM5BAA |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 5.0 inch | Designed For |
|
|
| Maximum Ratings : | OP Temperature | -30 ~ 80 °C | ST Temperature | -30 ~ 80 °C |
| Vibration Level | 2.0G (19.6 m/s²) | RoHS | |
|
| Features : |
|
|||
| Basic Information : | Luminance | 600 cd/m² (Typ.) | Contrast Ratio | 350 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | - | |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.290; Wy:0.310 | Support Color | 262K (6-bit) |
| Color Temperature | 8266K | White Uniformity | - | |
| 1931 Color Gamlt : | NTSC Ratio | 61% | sRGB | 84% coverage |
| Adobe RGB | 62% coverage | DCI-P3 | 63% coverage | |
| Rec.2020 | 45% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 640(RGB)×480 [VGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.053×0.159 mm | Pixel Pitch(W×H) | 0.159×0.159 mm [159PPI] | |
| Physical Size : | Active Viewing | 101.96(W)×76.32(H) mm | Overall Dim. | 119.4(W)×89.1(H) mm |
| Bezel Opening | 104.8(W)×79.36(H) mm | Overall Depth | 9.3±0.5 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | ||
| Other Detail : | Mass | 120g | Surface | Antiglare |
| Refresh Rate : | 60Hz Reverse Scan :
| Yes (U/D, L/R) |
|---|---|---|
| Power Consumption : | 150/180/230mA (Min./Typ./Max.) |
| Signal Electrical : | Input Current | 160/220mA (Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JAE | FI-SEB20P-HF13E | 1 pcs | 1.25 mm | 20 pins | ||
| Lamp Features: | Lamp Shape | - | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | - | Life | 70K(Typ.) (Hours) | |
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | With LED Driver | |||||
| Driver Electrical : | Input Current | 150/180/230mA (Min./Typ./Max.) | Input Voltage | 12.0V (Typ.) | ||
| Consumption | 2.7W (Typ.) | |||||
