Product Details:
|
| MODEL NUMBER: | G170HAN01.1 | BRAND: | AUO |
|---|---|---|---|
| SIZE: | 17INCH | RESOLUTION: | 1920×1920RGB |
| BRIGHTNESS: | 350CD/M2 | TEMPERATURE RANGE: | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| High Light: | 350CD/M2 AUO TFT Screen,17in AUO TFT Screen,1920×1920RGB TFT LCD Panel |
||
| Basic Detail : | Manufacturer | Model Name | G170HAN01.1 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 17.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -20 ~ 60 °C | ST Temperature | -20 ~ 70 °C |
| Vibration Level | 1.5G (14.7 m/s²) | RoHS |
| Basic Information : | Luminance | 350 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 13/12 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 71% | sRGB | 98% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 1920(RGB)×1920 | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.053×0.159 mm | Pixel Pitch(W×H) | 0.159×0.159 mm [159PPI] | |
| Physical Size : | Active Viewing | 305.28(W)×305.28(H) mm | Overall Dim. | 325.01(W)×319.33(H) mm |
| Bezel Opening | - | Overall Depth | 5.99/12.43 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 1:1 | Shape Style | ||
| Fixation : | Rear mounting holes (6-M3); Side mounting holes (4-M3) on left, right slugs | |||
| Other Detail : | Mass | 1.20Kgs (Max.) | Surface | Antiglare, Hard coating (2H), Antireflection |
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Power Consumption : | 15.36W (Typ.) |
| Signal Electrical : | Input Current | 1.28A (Typ.) | Input Voltage | 12.0V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | 15.36/16.9W (Typ./Max.) | Signal Interface | eDP (4 Lanes), eDP1.3 | |||
| Interface Features : | Position |  |
Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JAE | HD1S040HA1 | 1 pcs | 0.5 mm | 40 pins | ||
| Lamp Features: | Lamp Shape | 6 strings | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 10S6P | Life | 50K(Min.) (Hours) | |
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | With LED Driver | |||||
