Product Details:
|
| MODEL NUMBER: | G170HAN01.0 | BRAND: | AUO |
|---|---|---|---|
| SIZE: | 17INCH | RESOLUTION: | 1920×1920RGB |
| BRIGHTNESS: | 600CD/M2 | TEMPERATURE RANGE: | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| High Light: | 1920×1920RGB AUO TFT LCD,600CD/M2 AUO TFT LCD,16.32W WLED EDP TFT LCD |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| G170HAN01.0 | a-Si TFT-LCD , LCM | - | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| -20 ~ 60 °C | -20 ~ 70 °C | - | ||
| Designed For : |
|
|||
| Panel Size : | 17.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920(RGB)×1920 | RGB Vertical Stripe | 0.053×0.159 mm | 0.159×0.159 mm [159PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 305.28×305.28 mm | - | 325.01×319.33 mm | 5.8/12.2 (Typ./Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 1:1 (W : H) | Landscape type | ||
| Fixation : | Rear mounting holes (6-M3); Side mounting holes (4-M3) on left, right slugs | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 1.20Kgs (Max.) | Antiglare, Hard coating (3H) | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 600 cd/m² (Typ.) | AHVA, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Typ.)(CR≥10) | Symmetry | 13/12 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 71% | 99% | 74% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 74% | 53% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.25/1.33 (Typ./Max.)(5 points) | ||
| Power Consumption : | 16.32W (Typ.) |
|---|---|
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 1.36A (Typ.) | 12.0V (Typ.) | 16.32/17.95W (Typ./Max.) | ||||
| Interface Features : | Position | Type | Interface | |||
 |
Connector | eDP (4 Lanes), eDP1.3 | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| JAE | HD1S040HA1 | 1 pcs | 0.5 mm | 40 pins | ||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 6 strings | 9S6P | 50K(Min.) | - | |
| Interface Features : | Position | Type | WLED Driver | |||
| - | Included in panel signal interface | With LED Driver | ||||
