Product Details:
|
| MODEL NUMBER: | C089KAN01.0 | BRAND: | AUO |
|---|---|---|---|
| SIZE: | 8.9INCH | RESOLUTION: | 1280×272RGB |
| BRIGHTNESS: | 1750CD/M2 | TEMPERATURE RANGE: | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| Signal Interface: | LVDS | Lamp Type: | WLED |
| High Light: | 1750nits AUO TFT LCD,1280×272RGB AUO TFT LCD,8.9 Inch WLED LVDS TFT LCD |
||
The C089KAN01.0 is a 8.9 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 95°C . It's general features are summarized by Panelook in the following: Wide Temperature, Ultra High Brightness, WLED Backlight, Bar Display, 180° Reverse, Matte . Based on its features, Panelook recommend that this model be applied to Outdoor High Brightness, Stretched Bar LCD, Automotive Display etc. According to the information stored in Panelook this model mass production on Q3, 2016 and last shippment on Q4, 2020, Now this model is discontinued. There are 0 items stock and 3 suppliers of this model on Panelook. We inputted this model's specification on Jun 21 2019 for the first time, and the latest update on May 22 2023. If you want to embed C089KAN01.0 LCM in your future product, Panelook strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The C089KAN01.0 production status marked on Panelook.com is for reference only and should not be used as the basis for the user's decision making. All specification details are inputted by Panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
| Basic Info : | Panel Brand | Panel Model | C089KAN01.0 | |
|---|---|---|---|---|
| Diagonal Size | 8.9" (Native bar) | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -30 ~ 85 °C | Storage Temp. | -40 ~ 95 °C |
| RoHS State | Vibration Rating | - | ||
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 1280(RGB)×272 | Dot Pitch | 0.0573×0.1719 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.1719×0.1719 mm (H×V) [147PPI] | |
| Mechanical Size : | Display Area | 220.032×46.7568 mm (H×V) | Bezel Area | - |
| Outline Dim. | 231.292×62.3 mm (H×V) | Outline Depth | 8.8 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Free Form | Orientation | Landscape type |
| Aspect Ratio | >3:1 (H:V) | Shape Style | ||
| Other Features : | Weight | 181.7±18g | Surface | Antiglare |
| Basic Information : | Brightness | 1750 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Optical Mode | AHVA, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 9/11 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | - | Color Numbers | 16.7M (8-bit) |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
| Signal Systerm : | LVDS (1 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| HRS | FH52-40S-0.5SH | 0.5 mm | 40 pins | 1 pcs | ||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
