Product Details:
|
MODEL NUMBER: | G085VW01 V1 | BRAND: | AUO |
---|---|---|---|
SIZE: | 8.5INCH | RESOLUTION: | 800×480 RGB |
BRIGHTNESS: | 200CD/M2 | TEMPERATURE RANGE: | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -35 ~ 85 °C |
High Light: | 6 Bit TFT LCD Panel,LVDS Industrial LCD Screen |
Basic Information : | Brand | Model | G085VW01 V1 | |
---|---|---|---|---|
Type | LCM a-Si TFT-LCD | Used For | ||
Screen Size | 8.5" | Alias | G085VW01 V.1 | |
Environment : | Storage Temp. | -35 ~~ 85 °C | Operating Temp. | -30 ~~ 85 °C |
RoHS | Vibration | 1.5G (14.7 m/s²) |
Pixel Features : | Resolution | 800(RGB)×480, WVGA | Dot Pitch(mm) | 0.077×0.231 (H×V) |
---|---|---|---|---|
Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.231×0.231 (H×V) [109PPI] | |
Mechanical Size : | Active Area(mm) | 184.8(H) × 110.88(V) | Bezel Area(mm) | 189.8(H) × 116.0(V) |
Outline Dim.(mm) | 222.7(H) × 135.4(V) | Depth(mm) | 12.5 (Max.) | |
Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
Mounting : | Face mounting holes (4 pcs) on left, right bezel | |||
Other Spec : | Weight | 300g (Typ.) | Treatment | Antiglare, Hard coating (3H) |
Basic Information : | Luminance(cd/m²) | 200 (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
---|---|---|---|---|
Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
Best View on | - | Response(ms) | 20/10 (Typ.)(Tr/Td) | |
Color Performance : | White Coordinate | X:0.300; Y:0.320 | Display Colors | 262K (6-bit) |
Color Temperature | 7351K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) | |
1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 71% coverage |
Adobe RGB | 54% coverage | DCI-P3 | 54% coverage | |
Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Frame Rate : | 60Hz |
---|---|
Reverse Scan : | Yes (180°) |
Power Consumption : | 3.2W |
Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 135/150/200mA (Min./Typ./Max.) | ||
---|---|---|---|---|---|---|
Consumption | 0.5W (Typ.) | |||||
Signal Type : | TTL (1 ch, 6-bit) | Signal Voltage | - | |||
Interface Features : | Position | - | Type | Connector | ||
Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
HRS | FH12-40S-0.5SH(89) | 1 pcs | 40 pins | 0.5 mm | DRGB-40P1C6B-070A |
Backlight Features: | Shape | Straight | Type | CCFL | Position | Edge light type (Top side) |
---|---|---|---|---|---|---|
Replacement | - | Quantity | 1 pcs | Life Time | 50K(Typ.) (Hours) | |
Lamp Electrical : | Voltage Supply | 440V (Typ.) | Current Supply | 4.0/5.0/6.5mA (Min./Typ./Max.) | ||
Frequency | 45KHz (Min.) | Startup Voltage | 700/900V (Max.)(Ta=+25/0℃) | |||
Consumption | 2.7W (Typ.) | |||||
Interface Features : | Position | - | Type | Connector | ||
Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
JST | BHSR-02VS-1(N) | 1 pcs | 2 pins | 3.5 mm | BLL-2PINS-HL | |
Backlight Driver : | No |
