Product Details:
|
| MODEL NUMBER: | G070VAN01.0 | BRAND: | AUO |
|---|---|---|---|
| SIZE: | 7INCH | RESOLUTION: | 800×480 RGB |
| BRIGHTNESS: | 400CD/M2 | TEMPERATURE RANGE: | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| Highlight: | LVDS Industrial LCD Screen,Transmissive AUO TFT LCD |
||
| Basic Information : | Brand | Model | G070VAN01.0 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For |
|
|
| Screen Size | 7.0" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 80 °C | Operating Temp. | -30 ~~ 80 °C |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 800×480(RGB), WVGA | Dot Pitch(mm) | 0.1905×0.0635 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Horizontal Stripe | Pixel Pitch(mm) | 0.1905×0.1905 (H×V) [133PPI] | |
| Mechanical Size : | Active Area(mm) | 152.4(H) × 91.44(V) | Bezel Area(mm) | 154.2(H) × 93.24(V) |
| Outline Dim.(mm) | 166.6(H) × 107(V) | Depth(mm) | 7.0/10.0 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 175±10%g | Treatment | Antiglare |
| Basic Information : | Luminance(cd/m²) | 480 (Typ.) | Contrast Ratio | 1300:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 11/19 (Max.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.307; Y:0.321 | Display Colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Color Temperature | 6904K | White Uniformity | 1.25 (Typ.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 98% coverage |
| Adobe RGB | 75% coverage | DCI-P3 | 76% coverage | |
| Rec.2020 | 55% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Power Consumption : | 2.978W (Max.) |
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 0.14/0.20A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | LVDS (1 ch, 6/8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| STARCONN | 093G30-00001A-M4 | 1 pcs | 30 pins | 1.0 mm | ||
| Backlight Features: | Shape | Array | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 7S2P | Life Time | 50K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 22.4/25.2V (Typ./Max.) | Current Supply | 92mA (Typ.) | ||
| Consumption | 2.06W (Typ.) | |||||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
