Product Details:
|
| MODEL NUMBER: | C059VTN01.0 | BRAND: | AUO |
|---|---|---|---|
| SIZE: | 5.9INCH | RESOLUTION: | 1150×400RGB |
| BRIGHTNESS: | 740CD/M2 | TEMPERATURE RANGE: | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| High Light: | LVDS Industrial LCD Screen,Transmissive AUO TFT LCD |
||
| Basic Detail : | Manufacturer |  |
Model Name | C059VTN01.0 |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 5.9 inch | Designed For |
|
|
| Maximum Ratings : | OP Temperature | -30 ~ 85 °C | ST Temperature | -40 ~ 95 °C |
| Vibration Level | - | RoHS | |
| Basic Information : | Luminance | 740 cd/m² (Typ.) | Contrast Ratio | 700 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 12 o'clock | Response Speed | 15/20 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 60/60/60/40 (Typ.)(CR≥10) |
Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.301; Wy:0.330 | Support Color | 16.7M (8-bit) |
| Color Temperature | 7144K | White Uniformity | 1.25/1.33 (Typ./Max.) |
|
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Pixel Features : | Number of Pixel | 1150(RGB)×400 | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.041×0.123 mm | Pixel Pitch(W×H) | 0.123×0.123 mm [206PPI] | |
| Physical Size : | Active Viewing | 141.45(W)×49.2(H) mm | Overall Dim. | 155.6(W)×65.65(H) mm |
| Bezel Opening | 144.1(W)×51.0(H) mm | Overall Depth | 6.5 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | >3:1 | Shape Style | ||
| Other Detail : | Mass | 95±0.95g | Surface | - |
| Refresh Rate : | 60Hz Reverse Scan :
| Yes (U/D, L/R) |
|---|
| Signal Electrical : | Input Current | 24/19/0.13/0.16mA (Typ.)(IDD/AIDD/IGH/IGL) | Input Voltage | 3.3/13/15/-19V (Typ.)(VDD/AVDD/VGH/VGL) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS (1 ch, 8-bit) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 60 pins | |||||
C059VTN01.0 supports display 1150(RGB)×400 with aspect ratio of >3:1 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 141.45(W)×49.2(H) mm, outline size of 155.6(W)×65.65(H) mm, viewing area size of 144.1(W)×51.0(H) mm, net weight of 95±0.95g. As a TN, Normally White, Transmissive LCM product, C059VTN01.0 can provides 740 cd/m² display brightness 700:1 transimissive contrast ratio, 60/60/60/40 (Typ.)
