Product Details:
|
| SIZE: | 8.4 Inch | RESOLUTION: | 800×600(RGB) [SVGA] 118PPI |
|---|---|---|---|
| BRIGHTNESS: | 900cd/m2 (Typ.) | TEMPERATURE: | Operating Temperature: -30 ~ 90 °C ; Storage Temperature: -40 ~ 95 °C |
| Signal Interface: | Parallel RGB (1 Ch, 8-bit) + SPI , 60 Pins FPC | Lamp Type: | WLED , W/O Driver |
| Highlight: | 8.4" FPC Automotive TFT Displays,900cd/m2 Automotive TFT Displays,C084SAT01.0 |
||
As a distributor,Sapientia display provides technical support for the development of every type and class of LCD, from the design stage right through to the production phase, while guaranteeing the highest quality standards.
Our products can be customized for various applications and market sectors, including (but not limited to): automotive, medical, building automation, white goods, digital signage, security, transportation and industrial.
2.AUO C084SAT01.0 Mechanical Features:
| Screen Size : | 8.4" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 800×600(RGB), SVGA | RGB Horizontal Stripe | 0.2136×0.0712 mm | 0.2136×0.2136 mm [118PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 170.88×128.16 mm | - | 185.5×143.5 mm | 8 (Typ.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 4:3 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 365±73g | - | Antiglare, Reflection 3.0% (Max.) | ||
| Holes & Brackets : | Rear mounting Pole (8 pcs) | |||
3. AUO C084SAT01.0 Optical Features:
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 900 cd/m² (Typ.) | AHVA, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 80/80/80/80 (Typ.)(CR≥10) | 15/20 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| - | 16.7M (8-bit) | - | |
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - |
4.AUO C084SAT01.0 Interface Features:
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
|---|---|---|---|---|---|---|
| Parallel RGB (1 ch, 8-bit) + SPI | FPC | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| 1 pcs | 60 pins | 0.5 mm | ||||
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
