Product Details:
|
| Size: | 12.3 Inch | Screen Type: | A-Si TFT-LCD, LCM |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×720 166PPI | Luminance: | 700cd/m² (Typ.) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Contrast Ratio: | 1000 : 1 (Typ.) (TM) |
| Response: | 12/13 (Typ.)(Tr/Td) Ms | Backlight: | 10S2P WLED , 10K Hours , No Driver |
| Signal Type: | LVDS (2 Ch, 8-bit) , 40 Pins Connector | Max. Ratings: | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 M/s²) |
| Highlight: | 700cd/m² Automotive TFT Display,166PPI Automotive TFT Display,C123HAN01.1 |
||
1. HIGHEST QUALITY STANDARD DISPLAYS:
| Basic Information : | Luminance | 700 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 12/13 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.285; Wy:0.309 | Support Color | 16.7M (8-bit) |
| Color Temperature | 8696K | White Uniformity | 1.25 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 94% coverage |
| Adobe RGB | 73% coverage | DCI-P3 | 73% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
3. AUO C123HAN01.1 Mechanical Details:
| Pixel Features : | Number of Pixel | 1920(RGB)×720 | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.05075×0.15225 mm | Pixel Pitch(W×H) | 0.15225×0.15225 mm [166PPI] | |
| Physical Size : | Active Viewing | 292.32(W)×109.62(H) mm | Overall Dim. | 308.1(W)×134.86(H) mm |
| Bezel Opening | 294.82(W)×112.12(H) mm | Overall Depth | 7.6/15.6 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 8:3 | Shape Style | - | |
| Fixation : | Rear mounting Pole | |||
| Other Detail : | Mass | 590±59g | Surface | Antiglare |
4.AUO C123HAN01.1 Interface Details:
| Signal Electrical : | Input Current | 750mA (Max.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS (2 ch, 8-bit) | |||
| Interface Features | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| HRS | FH41-40S-0.5SH(05) | 1 pcs | 0.5 mm | 40 pins | ||
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
