Product Details:
|
| Size: | 24 Inch | Screen Type: | A-Si TFT-LCD, LCM |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 91PPI | Luminance: | 300cd/m² (Typ.) |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Contrast Ratio: | 5000 : 1 (Typ.) (TM) |
| Response: | 16/9 (Typ.)(Tr/Td) Ms | Backlight: | 10S7P WLED , 50K Hours , With LED Driver |
| Signal Type: | LVDS (2 Ch, 8-bit) , Connector 30 Pins | Max. Ratings: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| High Light: | 91PPI TFT LCD Panel,300cd/m² TFT LCD Panel,G240HW01 V1 |
||
1. HIGHEST QUALITY STANDARD DISPLAYS:
| Pixel Features | Pixel Format | 1920(RGB)×1080 [FHD] | Dot Pitch | 0.09225×0.27675 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.27675×0.27675 mm (H×V) [91PPI] | |
| Mechanical Size : | Display Area | 531.36×298.89 mm (H×V) | Bezel Area | 535.36×302.89 mm (H×V) |
| Outline Dim. | 556×323.2 mm (H×V) | Outline Depth | 17.0 (Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | - | |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features | Weight | 2.30±0.2Kgs | Surface | Antiglare, Hard coating (3H) |
| Basic Information : | Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 5000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Optical Mode | AMVA3, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 16/9 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 92% coverage |
| Adobe RGB | 71% coverage | DCI-P3 | 75% coverage | |
| Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
4.AUO G240HW01 V1 Backlight Details:
| Back-light Features: | Lamp Shape | 7 strings | Lamp Type | WLED | Life Time | 50K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 10S7P | Position | Edge light type (Bottom side) | |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| STM | MS24049HJ | 1.25 mm | 9 pins | 1 pcs | ||
| Driver Electrical | Voltage Input | 12.0V (Typ.) | Current Input | 1.2A (Typ.) | ||
| Consumption | 14.4/17.3W (Typ./Max.) | |||||
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
