Product Details:
|
| Size: | 12.1 Inch | Pixel Number: | 1024(2)×768(2) (XGA) 105PPI |
|---|---|---|---|
| Luminance: | 500 Cd/m² (Typ.) | Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) |
| Color Depth: | 262K/16.2M 70% NTSC | Signal Type: | LVDS (1 Ch, 6/8-bit) , 20 Pins Connector |
| Work Mode: | TN, Normally White, Transmissive | Touchscreen: | Without |
| Backlight: | 9S2P WLED , 50K Hours , With LED Driver | Max. Ratings: | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
| High Light: | G121XN01 V0,12.1 Inch AUO TFT LCD,20 pins AUO TFT LCD |
||
12.1 Inch Wide Temperature TFT LCD G121XN01 V0 With LED Driver Lamp Repaceable
1. Main Information:
G121XN01 V0 (Alias: G121XN01 V.0) is a 12.1" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp.
With an integral WLED backlight system, With LED Driver , without touch screen.
It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -30 ~ 85°C , and the maximal vibration level of 1.5G (14.7 m/s²).
It's general features are following: Wide Temperature, Lamp Repaceable, WLED Backlight, Life ≥ 50K hours, With LED Driver, Upside I/F, 180° Reverse, 6/8 bit, Matte .
Based on its features,this model be applied to Industrial etc.
2. AUO G121XN01 V0 Optical Details:
| Basic Information : | Luminance | 500 cd/m² (Typ.) | Contrast Ratio | 700 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | 25/10 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 262K/16.2M (6-bit / 6-bit + FRC) |
| Color Temperature | 6638K | White Uniformity | 1.33 (Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 71% | sRGB | 93% coverage |
| Adobe RGB | 72% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
3.AUO G121XN01 V0 Mechanical Details:
| Pixel Features : | Number of Pixel | 1024(2)×768(2) [XGA] | Arrangement | RGBW Rectangle |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.120×0.120 mm | Pixel Pitch(W×H) | 0.240×0.240 mm [105PPI] | |
| Physical Size : | Active Viewing | 245.76(W)×184.32(H) mm | Overall Dim. | 279(W)×209(H) mm |
| Bezel Opening | 250.8(W)×189.4(H) mm | Overall Depth | 6.0/9.0 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | - | |
| Fixation : | Face mounting holes (4-Φ3.4, 3-R1.7) on left and right bezel | |||
| Other Detail | Mass | 495g (Max.) | Surface | Antiglare, Hard coating (3H) |
4.AUO G121XN01 V0 Lightting Details:
| Lamp Features: | Lamp Shape | 2 strings | Lamp Type | WLED | Position | Edge light type (Top side) |
|---|---|---|---|---|---|---|
| Exchange | Replaceable | Amount | 9S2P | Life | 50K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 110mA (Typ.) | Input Voltage | 27.81/36V (Typ./Max.) | ||
| Consumption | 6.12/7.92W (Typ./Max.) | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| E&T | 3808K-F05N-02R | 1 pcs | 1.25 mm | 5 pins | ||
| Backlight Driver : | With LED Driver | |||||
| Driver Electrical : | Input Current | 600mA (Typ.) | Input Voltage | 10.8/12.0/12.6V (Min./Typ./Max.) | ||
