Product Details:
|
| Size: | 15 Inch | Resolution: | 1024*768 |
|---|---|---|---|
| Luminance: | 350 Cd/m² (Typ.) | Viewing Angle: | 85/85/80/80 (Typ.)(CR≥10) |
| Support Color: | 262K/16.2M 60% NTSC | Interface Type: | LVDS (1 Ch, 6/8-bit) , 20 Pins Connector |
| Response Time: | 5.7/2.3 (Typ.)(Tr/Td) | Operating Mode: | TN, Normally White, Transmissive |
| Light Source: | WLED , 50K Hours , With LED Driver | Environment: | Operating Temperature: 0 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
| High Light: | WLED AUO TFT LCD,Transmissive AUO TFT LCD,TN AUO TFT LCD |
||
| Screen Size | 15 Inch | |||
|---|---|---|---|---|
| Pixel Features | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1024(RGB)×768, XGA | RGB Vertical Stripe | 0.099×0.297 mm | 0.297×0.297 mm [85PPI] | |
| Mechanical Size | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 304.128×228.096 mm | 313.55×237.25 mm | 326.5×253.5 mm | 12.0 (Max.) mm | |
| Outline Features | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 4:3 | Landscape type | - | |
| Other Spec | Mass | Panel Cover | Surface Treatment | |
| 1.20Kgs (Max.) | - | Antiglare, Hard coating (3H) | ||
| Holes & Brackets | Side mounting holes (4-M3) on left, right bezel | |||
3.AUO G150XTN03.2 Optical Features:
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 250 cd/m² (Typ.) | TN, Normally White, Transmissive | 500:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| - | 45/45/20/40 (Typ.)(CR≥10) | 6/2 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6485K | 262K/16.2M (6-bit / 6-bit + FRC) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 60% | 83% | 62% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 62% | 45% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | ||
4.AUO G150XTN03.2 Backlight Features:
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type (Bottom side) | 30K(Min.) | - | - | No | |
| Interface Features : | WLED Driver State | Physical Type | Interface Position | |||
| With LED Driver | Connector | - | ||||
| Interface Detail | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| E&T | 3808K-F05N-02R | 1 pcs | 5 pins | 1.25 mm | ||
| WLED Driver Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 12.0±1.2V | 0.7A (Typ.) | 8.4/9.24W (Typ./Max.) | ||||
