Product Details:
|
| Brand: | Innolux | Diagonal Size: | 9.0" |
|---|---|---|---|
| Resolution: | 1280(RGB)×720, WXGA 163PPI | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Active Area: | 198.912(W)×111.888(H) Mm | Frequency: | 60Hz |
| Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| JJ090IA-01F | a-Si TFT-LCD , LCM | - | ||
| Maximum Ratings : | RoHS | Operating Temperature |
| Screen Size : | 9.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1280(RGB)×720, WXGA | RGB Vertical Stripe | 0.0518×0.1554 mm | 0.1554×0.1554 mm [163PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 198.912×111.888 mm | - | - | - | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 16:9 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| - | - | Hard coating | ||
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| - | AAS, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 85/85/85/85 (Typ.)(CR≥10) | 15/10 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6638K | 262K/16.7M (6-bit / 8-bit) | X:0.310; Y:0.330 | |
| White Uniformity : | 1.25/1.33 (Typ./Max.)(9 points) | ||
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | ||
| Refresh Rate : | 60Hz |
|---|
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 20K(Min.) | - | - | - | |
| Interface Features : | WLED Driver State | Physical Type | Interface Position | |||
| No | Included in signal interface | |||||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 198.912(W)×111.888(H) mm, with surface treament of Hard coating. As a AAS, Normally Black, Transmissive LCM product, JJ090IA-01F can provides 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 15/10 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. JJ090IA-01F utilizes LVDS as it's signal inputting systerm Connector.
