Product Details:
|
| Model: | LQ281L1LW11 | Brand: | Sharp |
|---|---|---|---|
| Outline Dim.: | 594(H)×594(V) Mm | Diagonal Size: | 28.1 Inch |
| Luminance: | 225 Cd/m² (Typ.) | Pixel Format: | 2048(RGB)×2048 103PPI |
| Environment: | Operating Temperature: 0 ~ 40 °C ; Storage Temperature: -25 ~ 60 °C | Light Source: | CCFL [21 Pcs] , 50K Hours , With Inverter |
| Highlight: | WLED High Brightness LCD Display,CCFL TFT LCD Screen,SVGA Sharp TFT LCD Display |
||
| Basic Information : | Brand | SHARP | Model | LQ281L1LW11 1 Compatible |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 28.1" | Alias | - | |
| Environment : | Storage Temp. | -25 ~~ 60 °C | Operating Temp. | 0 ~~ 40 °C |
| Basic Information : | Luminance(cd/m²) | 225 (Typ.) | Contrast Ratio | 450:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Display Mode | Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 5/20 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25 (Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 63% | sRGB | 84% coverage |
| Adobe RGB | 66% coverage | DCI-P3 | 65% coverage | |
| Rec.2020 | 47% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Backlight Features: | Shape | Straight | Type | CCFL | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 21 pcs | Life Time | 50K(Min.) (Hours) | |
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| HRS | RP13A-12RC-20PB | 1 pcs | 20 pins | NA | ||
| HRS | HIF3BA-10PA-2.54DS | 1 pcs | 10 pins | 2.54 mm | ||
| JST | S5B-PH-SM3-TB | 1 pcs | 5 pins | 2.0 mm | ||
| Backlight Driver : | With Inverter | |||||
| Pixel Features : | Resolution | 2048(RGB)×2048 | Dot Pitch(mm) | 0.082×0.246 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.246×0.246 (H×V) [103PPI] | |
| Mechanical Size : | Active Area(mm) | 503.808(H) × 503.808(V) | Bezel Area(mm) | 509.0(H) × 509.0(V) |
| Outline Dim.(mm) | 594(H) × 594(V) | Depth(mm) | 83.0 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 1:1 (H:V) | Orientation | Landscape type | |
| Mounting : | Face mounting holes; Rear mounting holes | |||
| Other Spec : | Weight | 15.0Kgs (Typ.) | Treatment | Antiglare, Hard coating (2H) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 1.30A (Typ.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | LVDS (8 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 3M | 10240-1210VE | 4 pcs | 40 pins | 0.635 mm | ||
LQ281L1LW11 can provides 225 cd/m² display brightness 450:1 transimissive contrast ratio, 85/85/85/85 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 5/20 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 63% (NTSC). This product adopted 21 pcs CCFL as it's backlight systerm which was placed as Direct light type and have a working life time of 50K hours, With Inverter. LQ281L1LW11 utilizes LVDS (8 ch, 8-bit) as it's signal inputting systerm, which connected by 160 pins Connector with power supply voltage of 12.0V (Typ.).
