Product Details:
|
| Panel Brand: | Sharp | Panel Model: | LQ281L1LW12 |
|---|---|---|---|
| Brightness: | 225cd/m² | Panel Size: | 28.1" |
| Panel Type: | A-Si TFT-LCD, LCM | Lamp Type: | CCFL , With Inverter |
| Signal Interface: | LVDS (8 Ch, 8-bit) , 160 Pins Connector | Resolution: | 2048(RGB)×2048, 103PPI |
| Environment: | Operating Temp.: 0 ~ 40 °C ; Storage Temp.: -25 ~ 60 °C | Bezel Opening: | 509.0(W)×509.0(H) Mm |
| Highlight: | WLED High Brightness LCD Display,CCFL TFT LCD Screen,SVGA Sharp TFT LCD Display |
||
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 225 (Typ.) | 85/85/85/85 (Typ.)(CR≥10) | 5/20 (Typ.)(Tr/Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | Normally Black, Transmissive | 450 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 63% | 84% | 66% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 65% | 47% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Panel Size : | 28.1" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 2048(RGB)×2048 | RGB Vertical Stripe | 0.246×0.246 [103PPI] | 0.082×0.246 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 503.808(H) × 503.808(V) | 509.0(H) × 509.0(V) | 594(H) × 594(V) | 60.0/83 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 1:1 (H:V) | ||
| Mounting : | Face mounting holes (4-Φ5.4), Rear mounting holes (4 pcs) | |||
| Other Detail : | Weight | Panel Cover | Treatment | |
| 15.0Kgs (Typ.) | - | Antiglare, Hard coating (2H) | ||
| Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
|---|---|---|---|---|---|---|
| CCFL | Direct light type | - | - | - | - | |
| Interface Features : | Position | Backlight Driver | Type | |||
| - | With Inverter | Connector | ||||
| Interface Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| HRS | RP13A-12RC-20PB | NA | 20 pins | 1 pcs | ||
| HRS | HIF3BA-10PA-2.54DS | 2.54 mm | 10 pins | 1 pcs | ||
| JST | S5B-PH-SM3-TB | 2.0 mm | 5 pins | 1 pcs | ||
| Driver Electrical : | Voltage Supply | Current Supply | Power Consumption | |||
| 12.0±6.0V | 13.5A (Max.) | - | ||||
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 12.0V (Typ.) | 1.30/2.0A (Typ./Max.) | - | ||||
| Interface Features : | Position | Signal | Type | |||
| - | LVDS (8 ch, 8-bit) | Connector | ||||
| Connector Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| 3M | 10240-1210VE | 0.635 mm | 40 pins | 4 pcs | ||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
