Product Details:
|
| Model: | LJ640U48 | Diagonal Size: | 9.4 Inch |
|---|---|---|---|
| Brand: | Sharp | Luminance: | 80 Cd/m² (Typ.) |
| Light Source: | Self | Pixel Format: | 640×480 [VGA] 84PPI |
| Outline Dim.: | 246(H)×180(V) ×25(D) Mm | Environment: | Operating Temperature: 0 ~ 55 °C ; Storage Temperature: -20 ~ 70 °C |
| High Light: | WLED High Brightness LCD Display,CCFL TFT LCD Screen,SVGA Sharp TFT LCD Display |
||
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| SHARP | LJ640U48 | EL , EL | - | |
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| 0 ~ 55 °C | -20 ~ 70 °C | - |
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 80 (Typ.) | - | - | |
| Best View on | Display Mode | Contrast Ratio | |
| - | - | 100 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | Monochrome | - |
| Panel Size : | 9.4" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 640×480 [VGA] | Rectangle | 0.30×0.30 [84PPI] | 0.30×0.30 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 191.9(H) × 143.9(V) | - | 246(H) × 180(V) | 25.0 (Max.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 4:3 (H:V) | ||
| Mounting : | Face mounting holes (2-Φ3.4, 2-Φ4.4) on left, right slugs | |||
| Other Detail : | Weight | Panel Cover | Treatment | |
| 700g | - | - | ||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
