Product Details:
|
| Diagonal Size: | 5.2INCH | Model: | LM24014H |
|---|---|---|---|
| Pixel Format: | 240×64 47PPI | Brand: | Sharp |
| Light Source: | EL | Bezel Area: | 132.6(H)×39(V) Mm |
| Active Area: | 127.15(H)×33.87(V) Mm | Environment: | Operating Temperature: 0 ~ 45 °C ; Storage Temperature: -25 ~ 60 °C |
| High Light: | SVGA Sharp TFT LCD Screen,XGA Industrial LCD Panel,LVDS TFT LCD Display |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LM24014H | STN-LCD , LCM | - | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 0 ~ 45 °C | -25 ~ 60 °C | - |
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| - | STN, Blue/Grey (Positive), Transflective | 7:1 (Typ.) (Reflective) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| - | - | 150/300 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| - | Monochrome | - | |
| Performance : | 3D Type | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - |
| Panel Size : | 5.2 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 240×64 | Rectangle | 0.53×0.53 mm | 0.53×0.53 mm [47PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 127.15×33.87 mm | 132.6×39 mm | 180×65 mm | 10.5 (Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | >3:1 (W : H) | Landscape type | ||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 120g | - | ||
LM24014H supports display 240×64 with aspect ratio of >3:1 (W:H), whose pixels are arranged in Rectangle. As for mechanical detail, it features active area of 127.15(W)×33.87(H) mm, outline size of 180(W)×65(H)×10.5(D) mm, viewing area size of 132.6(W)×39(H) mm, net weight of 120g. As a STN, Blue/Grey (Positive), Transflective LCM product, LM24014H can provides , 7:1 (Typ.) reflective contrast ratio , and response time of 150/300 (Typ.)(Tr/Td) ms., thus presenting a palette of Monochrome colors.
