Product Details:
|
| Brand: | Sharp | Model: | LQ035Q7DB03R |
|---|---|---|---|
| Type: | A-Si TFT-LCD , LCM | Diagonal Size: | 3.5 Inch |
| Light Source: | WLED | Pixel Format: | 240(RGB)×320 [QVGA] 113PPI |
| Luminance: | 55 Cd/m² (Typ.) | Environment: | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -25 ~ 75 °C |
| Contrast Ratio: | 85:1 (Typ.) (TM) | ||
| Highlight: | QVGA 113PPI Sharp TFT LCD Display,55cd/m2 Sharp TFT LCD Display,LQ035Q7DB03R |
||
LQ035 Series LQ035Q7DB03R LQ035Q7DB03F LQ035Q7DB03 LQ035Q7DB02R LQ035Q7DB02
| Basic Detail : | Manufacturer | SHARP | Model Name | LQ035Q7DB03R |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 3.5 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -10 ~ 60 °C | ST Temperature | -25 ~ 75 °C |
| Basic Information : | Luminance | 55 cd/m² (Typ.) | Contrast Ratio | 85 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | - | |
| Viewing Angle | - | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | - | Support Color | 262K (6-bit) |
| Pixel Features : | Number of Pixel | 240(RGB)×320 [QVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.0745×0.2235 mm | Pixel Pitch(W×H) | 0.2235×0.2235 mm [113PPI] | |
| Physical Size : | Active Viewing | 53.64(W)×71.52(H) mm | Overall Dim. | 65(W)×85(H) mm |
| Bezel Opening | - | Overall Depth | 3.4 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio(W:H) | 3:4 | Shape Style |
