Product Details:
|
| Manufacturer: | Sharp | Model Name: | LQ038Q5DR02 |
|---|---|---|---|
| Pixel Number: | 320(RGB)×240 (QVGA) 106PPI | Screen Size: | 3.8 Inch |
| Backlight: | 1 Pcs CCFL | Max. Ratings: | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 60 °C |
| Screen Type: | LCM , A-Si TFT-LCD | Arrangement: | RGB Vertical Stripe |
| High Light: | LVDS TFT LCD Panel,WLED LVDS TFT Touch Panel |
||
LQ038 Series LQ038Q5DR02 LQ038Q5DR01
| Basic Info : | Panel Brand | SHARP | Panel Model | LQ038Q5DR02 |
|---|---|---|---|---|
| Diagonal Size | 3.8" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -30 ~ 60 °C | Storage Temp. | -30 ~ 85 °C |
| RoHS State | Vibration Rating | - |
| Pixel Features : | Pixel Format | 320(RGB)×240 [QVGA] | Dot Pitch | 0.082×0.2235 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.246×0.2235 mm (H×V) [106PPI] | |
| Mechanical Size : | Display Area | 78.72×53.64 mm (H×V) | Bezel Area | - |
| Outline Dim. | 117.6×69.45 mm (H×V) | Outline Depth | 13.45 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 15:10 (H:V) | Shape Style | ||
| Other Features : | Weight | 125±10g | Surface | - |
| Frame Frequency : | 60Hz |
|---|---|
| Reverse Scan : | Yes (180°) |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
