Product Details:
|
| Panel Model: | LQ065T5DG05 | Panel Brand: | Sharp |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD , LCM | Pixel Format: | RGB Vertical Stripe |
| Panel Size: | 6.5" | Resolution: | 480(RGB)×234, 82PPI |
| Lamp Type: | 1 Pcs CCFL | Signal Interface: | Parallel RGB (1 Ch, 6-bit) |
| High Light: | QVGA Sharp TFT LCD Display,Symmetry Sharp TFT Panel |
||
LQ065 Series LQ065T5DG05 LQ065T5DG04 LQ065T5DG01
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| SHARP | LQ065T5DG05 | a-Si TFT-LCD , LCM | - |
| Screen Size : | 6.5" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 480(RGB)×234 | RGB Vertical Stripe | 0.100×0.339 mm | 0.300×0.339 mm [82PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 144×79.326 mm | - | - | - | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 16:9 | Landscape type | ||
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| LQ065T5DG05 | a-Si TFT-LCD , LCM |
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | - | 1 pcs |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 144(W)×79.326(H) mm. As a TN, Normally White, Transmissive LCM product, LQ065T5DG05 can provides . Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted 1 pcs CCFL as it's backlight systerm which was placed as Edge light type. LQ065T5DG05 utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm. For more latest product detail of LQ065T5DG05 we strongly recommend that you should refer to datasheet listed on Panelook.com or contact with Sharp.
