Product Details:
|
| Model: | LQ058T5AR04 | Brand: | SHARP |
|---|---|---|---|
| Pixel Format: | 400(RGB)×234 80PPI | Luminance: | 400 Cd/m² (Typ.) |
| Diagonal Size: | 5.8 Inch | Configuration: | RGB Vertical Stripe |
| Light Source: | CCFL | Interface Type: | Analog |
| Highlight: | QVGA Sharp TFT LCD Display,Symmetry Sharp TFT Panel |
||
LQ058 Series LQ058T5GG03 LQ058T5AR04
| Basic Info : | Panel Brand | SHARP | Panel Model | LQ058T5AR04 |
|---|---|---|---|---|
| Diagonal Size | 5.8" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - |
| Pixel Features : | Pixel Format | 400(RGB)×234 | Dot Pitch | 0.106×0.307 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.318×0.307 mm (H×V) [80PPI] | |
| Mechanical Size : | Display Area | 127.2×71.8 mm (H×V) | Bezel Area | - |
| Outline Dim. | 145×89.3 mm (H×V) | Outline Depth | 17.1 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style |
| Basic Information : | Brightness | 400 cd/m² (Typ.) | Contrast Ratio | 250:1 (Min.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | - | Optical Mode | TN, Transmissive | |
| Viewing Direction | - | Response Time | - |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
