Product Details:
|
| Panel Model: | LQ070Y5DG30 | Panel Brand: | Sharp |
|---|---|---|---|
| Lamp Type: | WLED | Signal Interface: | Parallel RGB (1 Ch, 6-bit) FPC |
| Panel Size: | 7.0INCH | Resolution: | 800(RGB)×480, WVGA, 134PPI |
| Pixel Format: | RGB Vertical Stripe | Environment: | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| High Light: | CCFL Sharp TFT LCD Display,WLED LVDS TFT Touch Panel |
||
LQ070 Series LQ070Y5DG36 LQ070Y5DG30 LQ070Y5DG13 LQ070Y5DG12
| Basic Detail : | Manufacturer | SHARP | Model Name | LQ070Y5DG30 |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 7.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -30 ~ 85 °C | ST Temperature | -30 ~ 85 °C |
| Pixel Features : | Number of Pixel | 800(RGB)×480 [WVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.0652×0.171 mm | Pixel Pitch(W×H) | 0.1955×0.171 mm [134PPI] | |
| Physical Size : | Active Viewing | 156.4(W)×82.08(H) mm | Overall Dim. | 166(W)×93.2(H) mm |
| Bezel Opening | - | Overall Depth | 6.0 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 17:9 | Shape Style | ||
| Other Detail : | Mass | 160g (Max.) | Surface | - |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
