Product Details:
|
| Panel Model: | LQ088H9DR01R | Panel Brand: | Sharp |
|---|---|---|---|
| Panel Size: | 8.8INCH | Resolution: | 640(RGB)×240, HVGA, 77PPI |
| Lamp Type: | 2 Pcs CCFL | Signal Interface: | Parallel RGB (1 Ch, 6-bit) , 31 Pins Connector |
| Pixel Format: | RGB Vertical Stripe | Environment: | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| Highlight: | CCFL LVDS Industrial LCD Panel,CCFL NEC TFT Panel |
||
LQ088 Series LQ088H9DZ03 LQ088H9DZ01 LQ088H9DR01U LQ088H9DR01R
| Basic Detail : | Manufacturer | Model Name | LQ088H9DR01R | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 8.8 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -30 ~ 85 °C | ST Temperature | -30 ~ 85 °C |
| Basic Information : | Luminance | - | Contrast Ratio | - |
|---|---|---|---|---|
| Good View at | - | Response Speed | - | |
| Viewing Angle | - | Operating Mode | TN, Normally White, Transflective | |
| Color Performance : | Chromaticity | - | Support Color | 262K (6-bit) |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Pixel Features : | Number of Pixel | 640(RGB)×240 [HVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.109×0.327 mm | Pixel Pitch(W×H) | 0.327×0.327 mm [77PPI] | |
| Physical Size : | Active Viewing | 209.28(W)×78.48(H) mm | Overall Dim. | - |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 8:3 | Shape Style |
