Product Details:
|
| Model: | LQ088H9DZ03 | Brand: | Sharp |
|---|---|---|---|
| Luminance: | 250 Cd/m² (Typ.) | Diagonal Size: | 8.8 Inch |
| Pixel Format: | 640(RGB)×240 [HVGA] 77PPI | Light Source: | CCFL [2 Pcs] , 10K Hours , W/O Driver |
| Interface Type: | Parallel RGB (1 Ch, 6-bit) , 31 Pins Connector | Environment: | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 M/s²) |
| Highlight: | CCFL LVDS Industrial LCD Panel,CCFL NEC TFT Panel |
||
LQ088 Series LQ088H9DZ03 LQ088H9DZ01 LQ088H9DR01U LQ088H9DR01R
| Basic Information : | Luminance | 250 cd/m² (Typ.) | Contrast Ratio | 180 : 1 (Typ.) (Transmissive) 8:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Good View at | - | Response Speed | 10/15 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 50/50/45/45 (Typ.)(CR≥15) | Operating Mode | TN, Normally White, Transflective | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 262K (6-bit) |
| Color Temperature | 6485K | White Uniformity | 1.43 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 46% | sRGB | 63% coverage |
| Adobe RGB | 48% coverage | DCI-P3 | 48% coverage | |
| Rec.2020 | 34% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| 3D Tech | - | Reflectance | 4.4/5.5% (Min./Typ.) |
| Pixel Features : | Number of Pixel | 640(RGB)×240 [HVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.109×0.327 mm | Pixel Pitch(W×H) | 0.327×0.327 mm [77PPI] | |
| Physical Size : | Active Viewing | 209.28(W)×78.48(H) mm | Overall Dim. | 231.6(W)×103.3(H) mm |
| Bezel Opening | 214.6(W)×83.9(H) mm | Overall Depth | 14.4 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 8:3 | Shape Style | ||
| Fixation : | Rear mounting holes | |||
| Other Detail : | Mass | 370g (Max.) | Surface | Antiglare |
| Signal Electrical : | Input Current | 40/25/-20mA (Typ.)(ISH/IGH/IGL) | Input Voltage | 5/10/-10V (Typ.)(VSH/VGH/VGL) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | Parallel RGB (1 ch, 6-bit) | |||
| Logic Voltage for Signals : | VIL≤0.9V; 2.3V≤VIH | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| HRS | DF9MA-31P-1V | 1 pcs | 1.0 mm | 31 pins | DRGB-31P1C6B-100A | |
| Lamp Features: | Lamp Shape | Straight | Lamp Type | CCFL | Position | Edge light type (Top and Bottom) |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 2 pcs | Life | 10K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 4.0/5.0/5.5mA (Min./Typ./Max.) | Input Voltage | 630±70V | ||
| Frequency | 30/50/75KHz (Min./Typ./Max.) | Turn-on Voltage | 1296/1330V (Max.)(Ta=+25/-30℃) | |||
| Consumption | 6.3/7.7W (Typ./Max.) | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JST | BHR-02(8.0)VS-1N | 2 pcs | 8.0 mm | 2 pins | BLL-2PINS-HL | |
| Backlight Driver : | No | |||||
