Product Details:
|
| Panel Size: | 8.8INCH | Panel Model: | LQ088K9LA01 |
|---|---|---|---|
| Panel Brand: | Sharp | Resolution: | 1280(RGB)×480, DVGA, 155PPI |
| Display Area: | 209.28(W)×78.48(H) Mm | Panel Type: | A-Si TFT-LCD , LCM |
| Signal Interface: | RSDS (1 Channel) | Lamp Type: | WLED |
| Highlight: | CCFL LVDS Industrial LCD Panel,CCFL NEC TFT Panel |
||
LQ088 Series LQ088K9LA02 LQ088K9LA01
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| LQ088K9LA01 | a-Si TFT-LCD , LCM | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| - | - | - | |
| Best View on | Display Mode | Contrast Ratio | |
| - | Normally Black, Transflective | - | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | 262K (6-bit) | - | |
| Performance : | 3D Tech | Sunlight Visibility | Reflectance |
| - | Sunlight Readable | - |
| Panel Size : | 8.8" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 1280(RGB)×480 [DVGA] | RGB Vertical Stripe | 0.1635×0.1635 [155PPI] | 0.0545×0.1635 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 209.28(H) × 78.48(V) | - | - | - | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 8:3 (H:V) | ||
| Basic Detail : | Manufacturer | Model Name | LQ088K9LA01 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 8.8 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | - | ST Temperature | - |
