Product Details:
|
| Panel Model: | LQ101K5DZ01A | Panel Brand: | Sharp |
|---|---|---|---|
| Panel Size: | 10.1INCH | Brightness: | 500 Cd/m² (Typ.) |
| Lamp Type: | WLED , 10K Hours , With LED Driver | Signal Interface: | Parallel RGB (1 Ch, 8-bit) , 68 Pins Connector |
| Resolution: | 1280(RGB)×422, 133PPI | Environment: | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 M/s²) |
| High Light: | CCFL LVDS Industrial LCD Panel,CCFL NEC TFT Panel |
||
| Panel Size : | 10.1 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1280(RGB)×422 | RGB Vertical Stripe | 0.063×0.189 mm | 0.189×0.189 mm [133PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 242.88×80.07 mm | 244.88×82.1 mm | 259.7×96.5 mm | 15.0 (Typ.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | >3:1 (W : H) | Landscape type | ||
| Fixation : | Side mounting holes (4-M2.5) on left, right bezel, Rear mounting Pole (8-M3) | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 470g (Typ.) | Antiglare, Reflection 1.5% (Typ.) | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 500 cd/m² (Typ.) | ASV, Normally Black, Transmissive | 2000:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 85/85/85/85 (Typ.)(CR≥10) | Symmetry | 15/5 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 8022K | 16.2M (6-bit + FRC) | X:0.290; Y:0.320 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 65% | 86% | 67% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 67% | 48% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.18 (Typ.)(9 points) | ||
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 400/500mA (Typ./Max.) | 3.3V (Typ.) | - | ||||
| Interface Features : | Position | Type | Interface | |||
| - | Connector | Parallel RGB (1 ch, 8-bit) | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| HRS | FH41-68S-0.5SH(05) | 1 pcs | 0.5 mm | 68 pins | ||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | - | - | 10K(Min.) | - | |
| Interface Features : | Position | Type | WLED Driver | |||
| - | Included in panel signal interface | With LED Driver | ||||
| Driver Electrical : | Current Input | Voltage Input | Consumption | |||
| 370/750mA (Typ./Max.) | 7.0/13.5/18.0V (Min./Typ./Max.) | - | ||||
LQ101K5DZ01A supports display 1280(RGB)×422 with aspect ratio of >3:1 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 242.88(W)×80.07(H) mm, outline size of 259.7(W)×96.5(H) mm, viewing area size of 244.88(W)×82.1(H) mm, with surface treament of Antiglare, Reflection 1.5% (Typ.), net weight of 470g (Typ.). As a ASV, Normally Black, Transmissive LCM product, LQ101K5DZ01A can provides 500 cd/m² display brightness 2000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 15/5 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + FRC gray scale signal for each dot, thus presenting a palette of 16.2M colors, also with performance of color gamut 65% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 10K hours, With LED Driver.
