Product Details:
|
| Panel Model: | LQ108M1JW01 | Panel Brand: | Sharp |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 204PPI | Panel Size: | 10.8" |
| Signal Interface: | EDP (4 Lanes) , EDP1.3 , RBR (1.62G/lane) , 51 Pins Connector | Lamp Type: | 5S8P WLED , 15K Hours , Without Driver |
| Brightness: | 400cd/m² | Viewing Angle: | 80/80/80/80 |
| Pixel Format: | RGB Vertical Stripe | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| High Light: | LVDS TFT LCD Display,WLED High Brightness LCD Display |
||
| Panel Size : | 10.8 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920(RGB)×1080, FHD | RGB Vertical Stripe | 0.0415×0.1245 mm | 0.1245×0.1245 mm [204PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 239.04×134.46 mm | - | 250.2×149.1 mm | 2.3±0.2 mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 16:9 (W : H) | Landscape type | ||
| Fixation : | Without | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 197g (Max.) | Antiglare (Haze 24%), Hard coating (3H) | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 400 cd/m² (Typ.) | IPS, Normally Black, Transmissive | 800:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 80/80/80/80 (Typ.)(CR≥10) | Symmetry | 25 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 71% | 100% | 74% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 74% | 53% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.25/1.40 (Typ./Max.)(5 points) | ||
| Power Consumption : | 3.6W |
|---|---|
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 315/500mA (Typ./Max.) | 3.3V (Typ.) | 1.04/1.65W (Typ./Max.) | ||||
| Interface Features : | Position | Type | Interface | |||
| - | Connector | eDP (4 Lanes), eDP1.3, RBR (1.62G/lane) | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| I-PEX | 20584-051E-01 | 1 pcs | 0.3 mm | 51 pins | ||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 8 strings | 5S8P | 15K(Min.) | - | |
| WLED Electrical : | Current Input | Voltage Input | Consumption | |||
| 14mA (Typ.) | 28.5/29.5V (Typ./Max.) | 3.2/3.3W (Typ./Max.) | ||||
| Interface Features : | Position | Type | WLED Driver | |||
| - | Included in panel signal interface | No | ||||
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 40 pcs / box | 15.0 Kgs | 630×515×235 mm (L×W×H) |
