10.4" LCM 640×480RGB 200cd/m² LQ10D41 Sharp TFT LCD Display

Large Image : 10.4" LCM 640×480RGB 200cd/m² LQ10D41 Sharp TFT LCD Display

Product Details:

Place of Origin:	JAPAN
Brand Name:	SHARP
Certification:	ISO9001
Model Number:	LQ10D41

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/WESTERN UNION/ESCROW
Supply Ability:	200PCS

Contact Now

10.4" LCM 640×480RGB 200cd/m² LQ10D41 Sharp TFT LCD Display

Description

Panel Brand:	Sharp	Panel Model:	LQ10D41
Brightness:	200 Cd/m² (Typ.)	Panel Size:	10.4"
Lamp Type:	2 Pcs CCFL , 25K Hours , Without Driver	Signal Interface:	TTL (1 Ch, 6-bit) , 31 Pins Connector
Pixel Format:	RGB Vertical Stripe	Touch Screen:	Without
High Light:	LVDS TFT LCD Display , WLED High Brightness LCD Display

LQ10 Series LQ10D421 LQ10D42 LQ10D41 LQ10D36A

Sharp LQ10D41 Mechanical Details

Pixel Features :	Resolution 640(RGB)×480, VGA Dot Pitch(mm) 0.110×0.330 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.330×0.330 (H×V) [76PPI]
Mechanical Size :	Active Area(mm) 211.2(H) × 158.4(V) Bezel Area(mm) -
Outline Features :	Form Style Flat Rectangle Shape Style Aspect Ratio 4:3 (H:V) Orientation Landscape type

Sharp LQ10D41 Optical Details

Basic Information :	Luminance(cd/m²) 200 (Typ.) Contrast Ratio - Viewing Angle - Display Mode TN, Normally White, Transmissive Best View on - Response(ms) -
Color Performance :	White Coordinate - Display Colors 262K (6-bit)

Sharp LQ10D41 Interface Detail

Signal Type :	TTL (1 ch, 6-bit) Logic Voltage -
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration 1.0 mm 31 pins 1 pcs

Sharp LQ10D41 Application Details

Basic Information :	Brand		Model	LQ10D41
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	10.4"	Alias

FAQ:

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.

Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.

Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.

Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
