Product Details:
|
| Panel Model: | LQ10PX22 | Panel Size: | 10.0" |
|---|---|---|---|
| Viewing Angle: | 35/35/30/10 | Resolution: | 1024(RGB)×768, XGA, 128PPI |
| Lamp Type: | No B/L | Signal Interface: | Parallel RGB (2 Ch, 6-bit) , 80 Pins Connector |
| Bezel Opening: | 205.75(W)×155.06(H) Mm | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
| Highlight: | LVDS TFT LCD Display,WLED High Brightness LCD Display |
||
LQ10 Series LQ10PX22 LQ10PX21
| Pixel Features : | Pixel Format | 1024(RGB)×768 [XGA] | Dot Pitch | 0.066×0.198 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.198×0.198 mm (H×V) [128PPI] | |
| Mechanical Size : | Display Area | 202.752×152.064 mm (H×V) | Bezel Area | 205.75×155.06 mm (H×V) |
| Outline Dim. | 265×195 mm (H×V) | Outline Depth | 8.0 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Holes & Brackets : | Face mounting holes (4 pcs) | |||
| Other Features : | Weight | 430±20g | Surface | Clear, Hard coating (2H) |
| Basic Information : | Brightness | - | Contrast Ratio | 100:1 (Min.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 35/35/30/10 (Min.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 12 o'clock | Response Time | 30/50 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 262K (6-bit) |
| Color Temperature | 6485K | White Uniformity | - | |
| Dispaly Performance : | Outdoor Visibility | - | Transmittance | 5.6% (Typ.)(with Polarizer) |
| Signal Systerm : | Parallel RGB (2 ch, 6-bit) | Logic Voltage | VIL≤0.6V; 2.6V≤VIH | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 5.0V (Typ.)(VCC) | Current Input | 300/500mA (Typ./Max.) | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | KX14-80K2D | 0.8 mm | 80 pins | 1 pcs | DRGB-80P2C6B-050A | |
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 10 pcs / box | 8.5 Kgs | 464×379×309 mm |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
