Product Details:
|
| Panel Model: | LQ123K3LG01 | Panel Size: | 12.3Inch |
|---|---|---|---|
| Brightness: | 450 Cd/m² (Typ.) | Resolution: | 1280(RGB)×480, DVGA, 111PPI |
| Display Area: | 291.84(W)×109.44(H) Mm | Signal Interface: | LVDS (1 Ch, 6/8-bit) , 20 Pins Connector |
| Lamp Type: | WLED , 70K Hours , With LED Driver | Environment: | Operating Temp.: 0 ~ 75 °C ; Storage Temp.: -30 ~ 75 °C |
| Highlight: | LVDS TFT LCD Panel,SVGA Sharp TFT LCD Display |
||
LQ123 Series LQ123K3LG01 LQ123K1LG03
| Basic Information : | Luminance | 450 cd/m² (Typ.) | Contrast Ratio | 400 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 35 (Typ.)(Tr+Td) (ms) | |
| Viewing Angle | 65/65/50/60 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.312; Wy:0.344 | Support Color | 16.2M (6-bit + FRC) |
| Color Temperature | 6423K | White Uniformity | 1.33 (Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 94% coverage |
| Adobe RGB | 76% coverage | DCI-P3 | 76% coverage | |
| Rec.2020 | 55% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 1280(RGB)×480 [DVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.076×0.228 mm | Pixel Pitch(W×H) | 0.228×0.228 mm [111PPI] | |
| Physical Size : | Active Viewing | 291.84(W)×109.44(H) mm | Overall Dim. | 312.4(W)×130.4(H) mm |
| Bezel Opening | 295(W)×113.4(H) mm | Overall Depth | 10.8 (Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 8:3 | Shape Style | ||
| Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Detail : | Mass | 425g (Max.) | Surface | Antiglare, Hard coating |
| Signal Electrical : | Input Current | 320/420mA (Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | LVDS (1 ch, 6/8-bit) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| HRS | DF14H-20P-1.25H | 1 pcs | 1.25 mm | 20 pins | LVDS-20P1C8B-010F | |
| Lamp Features: | Lamp Shape | - | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | - | Life | 70K(Typ.) (Hours) | |
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JAE | FI-S6P-HFE | 1 pcs | 1.25 mm | 6 pins | ||
| Backlight Driver : | With LED Driver | |||||
| Driver Electrical : | Input Current | 370/420/470/520mA (Typ.)(IDD1/IDD2/IDD3/IDD4) | Input Voltage | 12.0V (Typ.) | ||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
