Product Details:
|
| Panel Model: | LQ150X1LG98 | Resolution: | 1024(RGB)×768 |
|---|---|---|---|
| Brightness: | 350 Cd/m² (Typ.) | Panel Size: | 15" |
| Lamp Type: | WLED , 50K Hours , With LED Driver | Signal Interface: | LVDS (1 Ch, 8-bit) , 20 Pins Connector |
| Viewing Angle: | 80/80/80/80 | Environment: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| High Light: | CCFL TFT LCD Screen,SVGA Sharp LCD Display |
||
LQ150 Series LQ150X1LG98 LQ150X1LG96 LQ150X1LG94 LQ150X1LG93
| Pixel Features : | |
|---|---|
| Mechanical Size : | |
| Outline Features : | |
| Holes & Brackets : | |
| Other Features : |
| Basic Information : | |
|---|---|
| Color Performance : | |
| 1931 Color Gamlt : |
| Back-light Features : | |
|---|---|
| Interface Features : | |
| Interface Detail : | |
| Driver Electrical : |
| Signal Systerm : | |
|---|---|
| Signal Electrical : | |
| Interface Features : | |
| Connector Detail : |
LQ150X1LG98 supports display 1024(RGB)×768 (XGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 304.128(W)×228.096(H) mm, outline size of 326.5(W)×253.5(H)×10.1(D) mm, viewing area size of 307.4(W)×231.3(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 995g (Typ.). As a TN, Normally White, Transmissive LCM product, LQ150X1LG98 can provides 350 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 30 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 55% (NTSC).
