Product Details:
|
| MODEL NUMBER: | TM030LDHT10 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 3.0 Inch | RESOLUTION: | 40(RGB)×400 [WQVGA] 156PPI |
| BRIGHTNESS: | 150 Cd/m² (Typ. | Viewing Angle: | 45/40/45/40 (Typ.)(CR≥10 |
| TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C | ||
| Highlight: | 240×400 RGB TIANMA LCD Panel,150nits TIANMA LCD Panel,156PPI TIANMA Tft Screen |
||
| Basic Detail : | Manufacturer | Model Name | TM030LDHT10 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 3.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80 °C |
| Vibration Level | - | RoHS | ||
| Features : |
|
|||
| Basic Information : | Luminance | 150 cd/m² (Typ.) | Contrast Ratio | 80 : 1 (Typ.) (Transmissive) 10:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Good View at | 5 o'clock | Response Speed | 30 (Typ.)(Tr+Td) (ms) | |
| Viewing Angle | 45/40/45/40 (Typ.)(CR≥10) | Operating Mode | ECB, Normally White, Transflective | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.331 | Support Color | 65K/262K |
| Color Temperature | 6628K | White Uniformity | 1.25/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 33% | sRGB | 46% coverage |
| Adobe RGB | 34% coverage | DCI-P3 | 34% coverage | |
| Rec.2020 | 24% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| 3D Tech | - | Reflectance | 7.27% (Typ.) |
| Pixel Features : | Number of Pixel | 240(RGB)×400 [WQVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.054×0.162 mm | Pixel Pitch(W×H) | 0.162×0.162 mm [156PPI] | |
| Physical Size : | Active Viewing | 38.88(W)×64.8(H) mm | Overall Dim. | 76.65(W)×46.48(H) mm |
| Bezel Opening | - | Overall Depth | 2.97±0.2 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio(W:H) | 3:5 | Shape Style | ||
| Other Detail : | Mass | 21.2g (Typ.) | Surface | Antiglare (Haze 63%), Hard coating |
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Driver IC : | COG Built-in HX8352B |
| Signal Electrical : | Input Current | - | Input Voltage | 1.8/3.3V (Typ.)(IOVCC/VCC) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | CPU | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| molex | 55909-0574 | 1 pcs | 0.4 mm | 50 pins | ||
| Lamp Features: | Lamp Shape | 1 string | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - (Nichia NSSW 306D) | Amount | 6S1P | Life | 20K(Typ.) (Hours) | |
| Lamp Electrical : | Input Current | 20mA (Typ.) | Input Voltage | 17.4V (Typ.) | ||
| Consumption | 348mW (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 336 pcs / box | 544×365×250 mm | 13.48±1.3 Kgs |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
