Product Details:
|
| MODEL NUMBER: | TM103XDHP01 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 10.3 Inch | RESOLUTION: | 1920(RGB)×720 200PPI |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) | Lamp Type: | WLED |
| SIGNAL LNTERFACE: | LVDS | TEMPERATURE RANGE: | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| Highlight: | TM103XDHP01 Tianma TFT,1920×720 RGB Tianma TFT,200PPI Tianma LCD Display |
||
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| TM103XDHP01 | a-Si TFT-LCD , LCM | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| -30 ~ 85 °C | -40 ~ 90 °C | - | ||
| Used For : | ||||
| Specific Features : |
|
|||
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| - | 88/88/88/88 (Typ.)(CR≥10) | 35 (Typ.)(Tr+Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | SFT, Normally Black, Transmissive | 1000 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 6782K | 16.7M (8-bit) | X:0.307; Y:0.332 | |
| White Variation : | 1.33/1.43 (Typ./Max.)(9 points) | ||
| Panel Size : | 10.3" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 1920(RGB)×720 | RGB Vertical Stripe | 0.1269×0.1269 [200PPI] | 0.0423×0.1269 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 243.65(H) × 91.37(V) | - | - | - | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 8:3 (H:V) | ||
| Mounting : | Rear mounting Pole (10 pcs) | |||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
