4.7" 720×1280 RGB 500cd/m2 Tianma TFT Panel TM046JDHG01 80/80/80/80 (Typ.)(CR≥10)

Large Image : 4.7" 720×1280 RGB 500cd/m2 Tianma TFT Panel TM046JDHG01 80/80/80/80 (Typ.)(CR≥10)

Product Details:

Place of Origin:	JAPAN
Brand Name:	TIANMA
Certification:	ISO9001
Model Number:	TM046JDHG01

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	100PCS

Contact Now

4.7" 720×1280 RGB 500cd/m2 Tianma TFT Panel TM046JDHG01 80/80/80/80 (Typ.)(CR≥10)

Description

MODEL NUMBER:	TM046JDHG01	BRAND:	TIANMA
SIZE:	4.7INCH	RESOLUTION:	720(RGB)×1280, WXGA, 314PPI
BRIGHTNESS:	500CD/M2	Viewing Angle:	80/80/80/80 (Typ.)(CR≥10)
TEMPERATURE RANGE:	Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
Highlight:	720×1280 RGB Tianma TFT Panel , 500cd/m2 Tianma TFT Panel , 4.7" Tianma Lcd Monitor

TIANMA TM046JDHG01 Application Details

Basic Detail :

Manufacturer

Model Name

TM046JDHG01

Panel Type

a-Si TFT-LCD , LCM

Another Name

Panel Size

4.7 inch

Designed For

Maximum Ratings :

OP Temperature

-20 ~ 70 °C

ST Temperature

-30 ~ 80 °C

RoHS

Vibration Level

Features :

TIANMA TM046JDHG01 Optical Details

Basic Information :

Luminance

500 cd/m² (Typ.)

Contrast Ratio

800:1 (Typ.) (Transmissive)

Good View at

Symmetry

Response Speed

25 (Typ.)(Tr+Td) ms

Viewing Angle

80/80/80/80 (Typ.)(CR≥10)

Operating Mode

SFT, Normally Black, Transmissive

Color Performance :

Chromaticity

Wx:0.301; Wy:0.312

Support Color

16.7M (8-bit)

Color Temperature

7419K

White Variation

1.18/1.25 (Typ./Max.)(9 points)

1931 Color Gamlt :

NTSC Ratio

72%

sRGB

97% coverage

Adobe RGB

75% coverage

DCI-P3

75% coverage

Rec.2020

54% coverage

Remarks

sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM046JDHG01 Mechanical Details

Pixel Features :

Number of Pixel

720(RGB)×1280, WXGA

Arrangement

RGB Vertical Stripe

Dot Pitch(W×H)

0.0269×0.0807 mm

Pixel Pitch(W×H)

0.0807×0.0807 mm [314PPI]

Physical Size :

Active Viewing

58.104(W)×103.296(H) mm

Overall Dim.

61.6(W)×113.18(H) mm

Bezel Opening

Overall Depth

1.43±0.1 mm

Outline Features :

Form Shape

Flat Rectangle

Orientation

Portrait type

Aspect Ratio(W:H)

9:16

Shape Style

Other Detail :

Mass

15.6g (Typ.)

Surface

TIANMA TM046JDHG01 Electronics Details

Refresh Rate :

60Hz

Reverse Scan :

Driver IC :

Built-in OTM1283A

TIANMA TM046JDHG01 Interface Details

Signal Electrical :

Input Current

Input Voltage

(1.8/2.8)/2.8V (Typ.)(IOVCC/VCI)

Consumption

Signal Interface

MIPI (4 data lanes)

Interface Features :

Position

Physical Type

Connector

Interface Detail :

Brand

Model

Pin Pitch

Pins

Amount

Pin Assignment

Panasonic

AXT626124

0.4 mm

26 pins

1 pcs

TIANMA TM046JDHG01 Lightting Details

Lamp Features :

Lamp Type

WLED

Amount

10S1P

Position

Edge light type

Exchange

Lamp Shape

1 string

Lamp Life

Lamp Electrical :

Input Voltage

29.0V (Typ.)

Input Current

20mA (Typ.)

Consumption

580mW (Typ.)

Interface Features :

Position

Physical Type

Included in panel signal interface

Backlight Driver :

TIANMA TM046JDHG01 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	144 pcs / box	8.67±0.43Kgs	544×365×250 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
