Product Details:
|
| Panel Model: | LQ156T3LW02 | Panel Size: | 15.6" |
|---|---|---|---|
| Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) | Resolution: | 1366(RGB)×768, WXGA, 100PPI |
| Outline Size: | 363.8(W)×215.9(H) Mm | Brightness: | 400cd/m² |
| Signal Interface: | LVDS (1 Ch, 8-bit) | Lamp Type: | WLED , With LED Driver |
| Touch Screen: | Without | Outline Dim.: | 363.8(H)×215.9(V) Mm |
| Highlight: | XGA Industrial LCD Panel,SVGA Sharp TFT LCD Screen |
||
LQ156 Series LQ156T3LW03 LQ156T3LW02 LQ156M3LW01
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| SHARP | LQ156T3LW02 | a-Si TFT-LCD , LCM | - | |
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
| - | - | - |
| Screen Size : | 15.6" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1366(RGB)×768, WXGA | RGB Vertical Stripe | 0.084×0.252 mm | 0.252×0.252 mm [100PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 344.232×193.536 mm | - | 363.8×215.9 mm | 10.8 (Typ.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 16:9 | Landscape type | ||
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 400 cd/m² (Typ.) | ASV, Normally Black, Transmissive | - | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 85/85/85/85 (Typ.)(CR≥10) | - | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| - | 16.2M (6-bit + FRC) | - |
LQ156T3LW02 supports display 1366(RGB)×768 (WXGA) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 344.232(W)×193.536(H) mm, outline size of 363.8(W)×215.9(H) mm. As a ASV, Normally Black, Transmissive LCM product, LQ156T3LW02 can provides 400 cd/m² display brightness, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry . Gray scale or the brightness of the sub-pixel is determined with a 6-bit + FRC gray scale signal for each dot, thus presenting a palette of 16.2M colors, also with performance of color gamut 76% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type, With LED Driver.
