RGB 320×240 340cd/M2 Tianma TFT TM057KVHG01 5.7 Inch 70/70/70/60 (Typ.)(CR≥10)

Large Image : RGB 320×240 340cd/M2 Tianma TFT TM057KVHG01 5.7 Inch 70/70/70/60 (Typ.)(CR≥10)

Product Details:

Place of Origin:	JAPAN
Brand Name:	TIANMA
Certification:	ISO9001
Model Number:	TM057KVHG01

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	300PCS

Contact Now

RGB 320×240 340cd/M2 Tianma TFT TM057KVHG01 5.7 Inch 70/70/70/60 (Typ.)(CR≥10)

Description

MODEL NUMBER:	TM057KVHG01	BRAND:	TIANMA
SIZE:	5.7INCH	RESOLUTION:	320(RGB)×240, QVGA, 70PPI
BRIGHTNESS:	340 Cd/m² (Typ.)	Viewing Angle:	70/70/70/60 (Typ.)(CR≥10)
TEMPERATURE RANGE:	Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
Highlight:	RGB 320×240 Tianma TFT , 340cd/m2 Tianma TFT , 5.7 Inch Tianma LCD Screen

TIANMA TM057KVHG01 Application Details

Basic Detail :	Manufacturer Model Name TM057KVHG01 Panel Type a-Si TFT-LCD , LCM Another Name - Panel Size 5.7 inch Designed For
Maximum Ratings :	OP Temperature -20 ~ 70 °C ST Temperature -30 ~ 80 °C RoHS Vibration Level -
Features :

TIANMA TM057KVHG01 Optical Details

Basic Detail :	Luminance 340 cd/m² (Typ.) Contrast Ratio 500:1 (Typ.) (Transmissive) Good View at 6 o'clock Response Speed 20 (Typ.)(Tr+Td) ms Viewing Angle 70/70/70/60 (Typ.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance :	Chromaticity Wx:0.324; Wy:0.362 Support Color 262K (6-bit) Color Temperature 5814K White Variation 1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 54% sRGB 73% coverage Adobe RGB 56% coverage DCI-P3 55% coverage Rec.2020 40% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM057KVHG01 Mechanical Details

Pixel Features :	Number of Pixel 320(RGB)×240, QVGA Arrangement RGB Vertical Stripe Dot Pitch(W×H) 0.120×0.360 mm Pixel Pitch(W×H) 0.360×0.360 mm [70PPI]
Physical Size :	Active Viewing 115.2(W)×86.4(H) mm Overall Dim. 144(W)×104.6(H) mm Bezel Opening 116.6(W)×87.8(H) mm Overall Depth 14.45 (Max.) mm
Outline Features :	Form Shape Flat Rectangle Orientation Landscape type Aspect Ratio(W:H) 4:3 Shape Style
Touchscreen :	TP Controller With touch controller TP Interface I²C Touch Points 2 points TP Technology PCAP
Fixation :	Rear mounting poles (4-Φ2.6)
Other Detail :	Mass TBD Surface Hard coating (6H) Panel Cover With Cover Lens

TIANMA TM057KVHG01 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	Yes (U/D, L/R)
Driver IC :	Built-in NT39413

TIANMA TM057KVHG01 Interface Detail

Signal Electrical :	Input Current 6.0/10.0mA (Typ./Max.) Input Voltage 3.3V (Typ.) Consumption - Signal Interface Parallel RGB (1 ch, 6-bit)
Logic Voltage :	0≤VIL≤0.3VCC; 0.78VCC≤VIH≤VDD
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment STARCONN 089H33-000100-G2-R 0.5 mm 33 pins 1 pcs

TIANMA TM057KVHG01 Lightting Details

Lamp Features :	Lamp Type WLED Amount 5S3P Position Edge light type Exchange - Lamp Shape 3 strings Lamp Life 50K(Typ.) (Hours)
Lamp Electrical :	Input Voltage 14.85/18.15V (Min./Max.) Input Current 25.0mA (Typ.) Consumption 1.24W (Typ.)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment JST SHLP-06V-S-B 1.0 mm 6 pins 1 pcs BLE-6PINS-AAACCC
Backlight Driver :	No

TIANMA TM057KVHG01 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	36 pcs / box	-	544×365×250 mm
