Product Details:
|
| MODEL NUMBER: | TM150XDHG01 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 15.0 Inch | RESOLUTION: | 1600(RGB)×1200 (UXGA) 133PPI |
| BRIGHTNESS: | 1000 Cd/m² (Typ. | Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10 |
| TEMPERATURE RANGE: | Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 70 °C | ||
| High Light: | RGB 1600×1200 Tianma TFT Panel,1000nits Tianma TFT Panel,UXGA 133PPI Tianma Display |
||
| Basic Info : | Panel Brand |  |
Panel Model | TM150XDHG01 |
|---|---|---|---|---|
| Diagonal Size | 15.0" | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -30 ~ 70 °C | Storage Temp. | -40 ~ 80 °C |
| RoHS State | |
Vibration Rating | - | |
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 1600(RGB)×1200 [UXGA] | Dot Pitch | 0.0635×0.1905 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.1905×0.1905 mm (H×V) [133PPI] | |
| Mechanical Size : | Display Area | 304.8×228.6 mm (H×V) | Bezel Area | 307.8×231.1 mm (H×V) |
| Outline Dim. | 318.7×242.5 mm (H×V) | Outline Depth | 6.0/6.5 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Holes & Brackets : | Side mounting holes (4-M2.5) on left, right bezel | |||
| Other Features : | Weight | 620g | Surface | Antiglare |
| Basic Information : | Brightness | 1000 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 12 o'clock | Response Time | 20 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 262K (6-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) |
|
| 1931 Color Gamlt : | NTSC Ratio | 54% | sRGB | 75% coverage |
| Adobe RGB | 56% coverage | DCI-P3 | 56% coverage | |
| Rec.2020 | 40% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance |
| Reverse Scan : | No |
|---|
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 30K(Typ.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| HRS | DF19L-14P-1H | 1.0 mm | 14 pins | 1 pcs | ||
| Driver Electrical : | Voltage Input | 12.0±1.2V | Current Input | 1.14/1.29A (Typ./Max.) | ||
| Signal Systerm : | LVDS (2 ch, 6-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 990mA (Typ.) | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| HRS | MDF76-30P-1C | 1.0 mm | 30 pins | 1 pcs | ||
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 15 pcs / box | 12.75 Kgs | 520×435×330 mm |
