Product Details:
|
| Manufacturer: | Sharp | Screen Size: | 23.1 Inch |
|---|---|---|---|
| Pixel Number: | 1600×1200RGB | Active Area(mm): | 470.4 × 352.8 (H×V) |
| Luminance: | 250 Cd/m² (Typ.) | Screen Type: | LCM , A-Si TFT-LCD |
| Backlight: | 6 Pcs CCFL , With Inverter | Max. Ratings: | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 45 °C |
| Highlight: | LVDS TFT LCD Display,CCFL Sharp TFT LCD Display |
||
LQ231 Series LQ231U1LW32 LQ231U1LW31 LQ231U1LW21
| Basic Information : | Brand | SHARP | Model | LQ231U1LW21 |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 23.1" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 45 °C |
| Typical Features : | ||||
| Remarks : | Expanded backlight brightness adjustment area | |||
| Pixel Features : | Resolution | 1600(RGB)×1200, UXGA | Dot Pitch(mm) | 0.098×0.294 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.294×0.294 (H×V) [86PPI] | |
| Mechanical Size : | Active Area(mm) | 470.4(H) × 352.8(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 530(H) × 432.8(V) | Depth(mm) | 32.5 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 5.50Kgs (Max.) | Treatment | - |
| Basic Information : | Luminance(cd/m²) | 250 (Typ.) | Contrast Ratio | - |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Display Mode | Transmissive | |
| Best View on | - | Response(ms) | - | |
| Color Performance : | White Coordinate | - | Display Colors | 16.7M (8-bit) |
