Product Details:
|
| Brand: | Sharp | MODEL NUMBER: | LS037V7DD05 |
|---|---|---|---|
| Resolution: | 480(RGB)×640, VGA, 217PPI | Size: | 3.7 Inch |
| Brightness: | 130 Cd/m² (Typ.) | Lamp Type: | WLED , Without Driver |
| Viewing Angle: | 40/40/40/40 (Typ.) | Environment: | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| High Light: | CCFL LVDS Industrial LCD Panel,QVGA Sharp TFT LCD Display |
||
LS037 Series LS037V7DD05 LS037V7DD06R LS037V7DD06
| Basic Detail : | Manufacturer | SHARP | Model Name | LS037V7DD05 |
|---|---|---|---|---|
| Panel Type | CG-Silicon , LCM | Another Name | - | |
| Panel Size | 3.7 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -10 ~ 60 °C | ST Temperature | -20 ~ 70 °C |
| Vibration Level | - | RoHS |
| Lamp Features: | Lamp Shape | 1 string | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | - | Life | - | |
| Lamp Electrical : | Input Current | 15/20mA (Typ./Max.) | Input Voltage | 32.4/37.8V (Typ./Max.) | ||
| Consumption | 486mW (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
| Signal Electrical : | Input Current | 2.3/5.5/0.7/0.6/0.1mA (Typ.)(ISHD/ISHA/IDD/ISSD/IEE) | Input Voltage | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/VEE) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | Parallel RGB (1 ch, 6-bit) | |||
| Logic Voltage for Signals : | 0≤VIL≤0.2VSHD; 0.8VSHD≤VIH≤VSHD | |||||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 61 pins | |||||
| Refresh Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (U/D, L/R) |
| Time Controller (T-CON) : | Need external T-CON |
| Pixel Features : | Number of Pixel | 480(RGB)×640 [VGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.039×0.117 mm | Pixel Pitch(W×H) | 0.117×0.117 mm [217PPI] | |
| Physical Size : | Active Viewing | 56.16(W)×74.88(H) mm | Overall Dim. | 65(W)×90.4(H) mm |
| Bezel Opening | - | Overall Depth | 4.3 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio(W:H) | 3:4 | Shape Style | ||
| Touchscreen : | TP Controller | Without touch controller | TP Interface | - |
| Touch Points | - | TP Technology | 4-wire Resistive Touch | |
| Other Detail : | Mass | TBD | Surface | Hard coating (3H) |
| Basic Information : | Luminance | 130 cd/m² (Typ.) | Contrast Ratio | 100 : 1 (Typ.) (Transmissive) 2.5:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 20/20 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥2) | Operating Mode | TN, Normally White, Transflective | |
| Color Performance : | Chromaticity | Wx:0.300; Wy:0.310 | Support Color | 262K (6-bit) |
| Color Temperature | 7525K | White Uniformity | 1.25/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 22% | sRGB | 31% coverage |
| Adobe RGB | 24% coverage | DCI-P3 | 23% coverage | |
| Rec.2020 | 17% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| 3D Tech | - | Reflectance | 4/6% (Min./Typ.) |
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 50 pcs / box | - | - |
