Product Details:
|
| MODEL NUMBER: | TM017FDH03 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 1.8 Inch | RESOLUTION: | 128(RGB)×160 115PPI |
| BRIGHTNESS: | 250CD/M2 | Lamp Type: | WLED |
| SIGNAL LNTERFACE: | LVDS | Viewing Angle: | 45/45/50/20 (Typ.)(CR≥10 |
| TEMPERATURE RANGE: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C | ||
| Highlight: | WLED Backlight Tianma TFT,WQVGA TIANMA LCD Panel |
||
| Basic Information : | Brand | Model | TM017FDH03 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 1.8" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 80 °C | Operating Temp. | -20 ~~ 70 °C |
| RoHS | Vibration | - | ||
| Typical Features : |
|
|||
| Remarks : | CPU 8 bits | |||
| Pixel Features : | Resolution | 128(RGB)×160 | Dot Pitch(mm) | 0.073×0.219 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.219×0.219 (H×V) [115PPI] | |
| Mechanical Size : | Active Area(mm) | 28.032(H) × 35.04(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 34.7(H) × 47(V) | Depth(mm) | 2.60 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:5 (H:V) | Orientation | Portrait type | |
| Other Spec : | Weight | 6.70g | Treatment | Clear, Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 250 (Typ.) | Contrast Ratio | 350:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 45/45/50/20 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 30 (Typ.)(Tr+Td) | |
| Color Performance : | White Coordinate | X:0.288; Y:0.308 | Display Colors | 65K/262K |
| Color Temperature | 8480K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 43% | sRGB | 59% coverage |
| Adobe RGB | 44% coverage | DCI-P3 | 44% coverage | |
| Rec.2020 | 32% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Reverse Scan : | No |
|---|---|
| Driver IC : | Built-in HX8353-C |
| Signal Electrical : | Voltage Supply | 2.8/2.8V (Typ.)(VDD1/VDD2) | Current Supply | - | ||
|---|---|---|---|---|---|---|
| Signal Type : | CPU | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 25 pins | 0.8 mm | ||||
| Backlight Features: | Shape | Parallel | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 1S2P | Life Time | 20K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 3.2V (Typ.) | Current Supply | 15mA (Typ.) | ||
| Consumption | 96mW (Typ.) | |||||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 792 pcs / box | 11.10 Kgs | 544×365×250 mm (L×W×H) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
