Product Details:
|
| MODEL NUMBER: | TM030LDHT2 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 3.0 Inch | RESOLUTION: | 240(RGB)×400 (WQVGA) 156PPI |
| BRIGHTNESS: | 130 Cd/m² (Typ.) | Lamp Type: | WLED |
| SIGNAL LNTERFACE: | LVDS | Viewing Angle: | 40/45/55/40 (Typ.)(CR≥10) |
| TEMPERATURE RANGE: | 30 ~ 80 °C Operating Temp.: -20 ~ 70 °C | ||
| Highlight: | WLED Backlight Tianma TFT,WQVGA TIANMA LCD Panel |
||
| Basic Detail : | Manufacturer | Model Name | TM030LDHT2 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 3.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80 °C |
| Basic Information : | Luminance | 130 cd/m² (Typ.) | Contrast Ratio | 100 : 1 (Typ.) (Transmissive) 8:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Good View at | 12 o'clock | Response Speed | 35 (Typ.)(Tr+Td) (ms) | |
| Viewing Angle | 40/45/55/40 (Typ.)(CR≥10) | Operating Mode | ECB, Normally White, Transflective | |
| Color Performance : | Chromaticity | Wx:0.300; Wy:0.330 | Support Color | 65K/262K |
| Color Temperature | 7203K | White Uniformity | - | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Pixel Features : | Number of Pixel | 240(RGB)×400 [WQVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.054×0.162 mm | Pixel Pitch(W×H) | 0.162×0.162 mm [156PPI] | |
| Physical Size : | Active Viewing | 38.88(W)×64.8(H) mm | Overall Dim. | 47.28(W)×76.4(H) mm |
| Bezel Opening | 39.88(W)×65.8(H) mm | Overall Depth | ||
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio(W:H) | 3:5 | Shape Style | ||
| Other Detail : | Mass | - | Surface | Hard coating (3H) |
| Refresh Rate : | 60Hz |
|---|
without backlight driver, without touch screen. TM030LDHT2 supports display 240(RGB)×400 (WQVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 38.88(W)×64.8(H) mm, outline size of 47.28(W)×76.4(H) mm, viewing area size of 39.88(W)×65.8(H) mm, with surface treament of Hard coating (3H). As a ECB, Normally White, Transflective LCM product, TM030LDHT2 can provides 130 cd/m² display brightness 100:1 transimissive contrast ratio, 8:1 (Typ.) reflective contrast ratio, 40/45/55/40 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 35 (Typ.)(Tr+Td) ms., thus presenting a palette of 65K/262K colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type, external backlight driver is additionally needed
