Product Details:
|
| MODEL NUMBER: | TM020HDH03 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 2.0 Inch | RESOLUTION: | 240(RGB)×320, QVGA, 201PPI |
| BRIGHTNESS: | 200 Cd/m² (Typ.) | Viewing Angle: | 60/60/55/60 (Typ.)(CR≥10) |
| TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C | ||
| High Light: | WLED Backlight Tianma TFT,WQVGA TIANMA LCD Panel |
||
| Basic Info : | Panel Brand | Panel Model | TM020HDH03 | |
|---|---|---|---|---|
| Diagonal Size | 2.0" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 80 °C |
| RoHS State | Vibration Rating | - | ||
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 240(RGB)×320 [QVGA] | Dot Pitch | 0.042×0.126 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.126×0.126 mm (H×V) [201PPI] | |
| Mechanical Size : | Display Area | 30.24×40.32 mm (H×V) | Bezel Area | - |
| Outline Dim. | 44.04×49.75 mm (H×V) | Outline Depth | 2.45±0.1 mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio | 3:4 (H:V) | Shape Style | ||
| Other Features : | Weight | TBD | Surface | Clear, Hard coating (3H |
| Basic Information : | Brightness | 200 cd/m² (Typ.) | Contrast Ratio | 350:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 60/60/55/60 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 9 o'clock | Response Time | 25 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.297; Wy:0.319 | Color Numbers | 65K/262K |
| Color Temperature | 7564K | White Uniformity | - | |
| 1931 Color Gamlt : | NTSC Ratio | 50% | sRGB | 71% coverage |
| Adobe RGB | 52% coverage | DCI-P3 | 52% coverage | |
| Rec.2020 | 37% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| D-IC Detail : | COG Built-in ILI9335 |
|---|
| Back-light Features: | Lamp Shape | Parallel | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 1S3P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 3.2V (Typ.) | Current Input | 15mA (Typ.) | ||
| Consumption | 144mW (Typ.) | |||||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 768 pcs / box | TBD | 544×365×250 mm |
| Signal Systerm : | CPU | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 2.8V (Typ.) | Current Input | 4.6mA (Typ.) | ||
| Interface Features : | Type | FPC | Position | - | ||
| FPC Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 0.8 mm | 37 pins | 1 pcs | ||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
