Product Details:
|
| MODEL NUMBER: | NL204153AM21-24A | BRAND: | NEC |
|---|---|---|---|
| SIZE: | 21.3INCH | RESOLUTION: | 2048×1536RGB |
| BRIGHTNESS: | 1700CD/M2 | Lamp Type: | WLED |
| TEMPERATURE RANGE: | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C | ||
| High Light: | 6 Bit NEC TFT Display,40% NTSC NEC TFT Display |
||
| Basic Info : | Panel Brand | Panel Model | NL204153AM21-24A | |
|---|---|---|---|---|
| Diagonal Size | 21.3" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | 0 ~ 60 °C | Storage Temp. | -20 ~ 60 °C |
| RoHS State | Vibration Rating | 1.2G (11.76 m/s²) | ||
| Specific Features : |
|
|||
| Pixel Features : | Pixel Format | 2048(LCR)×1536 [QXGA] | Dot Pitch | 0.0705×0.2115 mm (H×V) |
|---|---|---|---|---|
| Configuration | LCR Vertical Stripe | Pixel Pitch | 0.2115×0.2115 mm (H×V) [120PPI] | |
| Mechanical Size : | Display Area | 433.152×324.864 mm (H×V) | Bezel Area | - |
| Outline Dim. | 457×350 mm (H×V) | Outline Depth | 21.5 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Weight | 2.70/2.98Kgs (Typ./Max.) | Surface | Antiglare, Hard coating (2H) |
| Basic Information : | Brightness | 1700 cd/m² (Typ.) | Contrast Ratio | 1400:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Optical Mode | SA-SFT, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 20/20 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.299; Wy:0.315 | Color Numbers | Grayscale (10-bit) |
| Color Temperature | 7502K | White Uniformity | 1.25 (Max.)(9 points) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
| Signal Systerm : | LVDS (4 ch, 10-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | 590/980mA (Typ./Max.) | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-RE51S-HF | 0.5 mm | 51 pins | 1 pcs | ||
| JAE | FI-RE41S-HF | 0.5 mm | 41 pins | 1 pcs | ||
| JAE | IL-Z-12PL-SMTYE | 1.25 mm | 12 pins | 1 pcs | ||
